APC by Schneider Electric Surgearrest PM 240/120V 80KA Non-modular - Surge Suppressor - PMP2X-A

APC by Schneider Electric PMP2X-A Surge Suppressor 240/120V 80kA Non-Modular

Overview

The APC by Schneider Electric PMP2X-A is a non-modular, commercial-grade surge suppressor rated for 120V/230V dual-voltage environments with an 80,000A normal-mode peak current rating. Built for installations where transient voltage spikes pose a real threat to connected equipment — industrial control panels, security infrastructure, AV systems, and sensitive networking gear — this unit delivers high-capacity surge diversion backed by UL 1449 and UL 1283 certifications. The black, wall-mountable form factor fits neatly into equipment rooms or panel enclosures where hardwired protection is preferred over point-of-use strips. If you're specifying APC by Schneider Electric power protection for a hardened installation, the PMP2X-A is the non-modular entry point at this surge capacity level.

Key Features

• 80,000A Normal-Mode Peak Current: The PMP2X-A is rated to handle up to 80kA of surge current in normal mode — enough headroom to survive direct nearby lightning strike events without sacrificing the connected load. On a 120/230V circuit feeding a rack of network equipment, that rating matters when a regional storm season arrives.
• 40,000A Common-Mode Protection: Common-mode surges (between neutral and ground, or hot and ground) are frequently overlooked but equally destructive to sensitive electronics. The 40kA common-mode rating addresses this vector directly — critical for systems with long cable runs between buildings or equipment in mixed-use facilities.
• 30dB EMI/RFI Noise Filtering: Electrical noise from HVAC motors, fluorescent ballasts, and variable-frequency drives contaminates power and degrades performance of connected cameras, recorders, and network switches. The 30dB attenuation from this unit's filtering stage cleans the incoming line before it reaches downstream equipment — relevant in manufacturing or warehouse environments where motor loads share the same panel.
• Dual-Voltage 120V/230V Input: Rated for both 120V and 230V environments, this unit supports international deployments or domestic installations with mixed voltage feeds. The 3-wire (2PH + G) input configuration accommodates standard branch circuit wiring in commercial and light industrial settings.
• UL 1449 and UL 1283 Certified: UL 1449 is the primary North American safety standard for surge protective devices — its listing means the unit has been independently tested for suppression voltage ratings and fail-safe behavior. UL 1283 covers electromagnetic interference filtering. Both certifications reduce insurance and inspection friction on commercial projects.
• Wide Operating Temperature Range (-20°C to 70°C): The -20°C to 70°C operating range means this unit can be deployed in unheated equipment enclosures, outdoor telecom cabinets (with appropriate housing), or rooftop mechanical rooms where temperatures swing significantly. Most consumer-grade suppressors are rated only down to 0°C.
• Compact 239 x 74 x 122mm Footprint: At under 240mm wide and weighing 6.7 lbs, the PMP2X-A fits into tight panel spaces without consuming a full DIN-rail slot or requiring a dedicated enclosure. The compact depth of 74mm keeps it flush against back panels.
• Non-Modular Design: The non-modular configuration means no field-replaceable MOV modules — the unit is replaced as a whole when end-of-life. This simplifies inventory management for smaller deployments but should factor into your serviceability planning for mission-critical sites where minimizing downtime requires hot-swap capability.

Integration & Compatibility

The PMP2X-A is designed for hardwired integration at the branch circuit or equipment panel level. Its 3-wire (2PH + G) input termination connects to standard commercial wiring without adapters. The dual 120V/230V rating means it installs without modification in either North American or international voltage environments. Compatible with a broad range of surge protection and power conditioning applications including IP surveillance systems, network closets, industrial control enclosures, and AV equipment racks. The unit's 50–60Hz frequency tolerance covers both North American and European grid frequencies, supporting deployments across regions. For full system power protection, pair this unit with a compatible UPS for battery backup on the same circuit — surge suppression and runtime backup are complementary, not interchangeable. When specifying protection for PoE switches and NVRs, consult a power protection planning guide to size the suppressor correctly relative to connected load impedance.

Frequently Asked Questions

Q: What is the peak surge current rating of the PMP2X-A?

A: The PMP2X-A is rated at 80,000A (80kA) peak current in normal mode and 40,000A (40kA) in common mode. These ratings reflect the maximum single-event surge the unit can divert without failure.

Q: What voltages does the PMP2X-A support?

A: The unit supports both 120V and 230V AC input at 50–60Hz, making it suitable for North American and international installations. The input connection is 3-wire (2PH + G).

Q: What certifications does the PMP2X-A carry?

A: The PMP2X-A is certified to UL 1449 (surge protective devices) and UL 1283 (electromagnetic interference filtering). These are the primary North American safety and performance standards for this product class.

Q: What is the EMI/RFI filtering level on the PMP2X-A?

A: The unit provides 30dB of EMI/RFI noise attenuation, which reduces electrical interference from motor loads, ballasts, and other noise sources on shared branch circuits.

Q: What is the operating temperature range of the PMP2X-A?

A: The PMP2X-A operates from -20°C to 70°C (-4°F to 158°F), allowing installation in unheated enclosures, mechanical rooms, and outdoor telecom cabinets where temperature swings are common.

Q: Is the PMP2X-A a modular unit with replaceable components?

A: No. The PMP2X-A is a non-modular design. There are no field-replaceable MOV modules — the entire unit is replaced at end of service life. Factor this into serviceability planning for high-availability installations.

Eden Phillips

The PMP2X-A is one of the higher-capacity non-modular surge suppressors in the APC hardwired line — that 80kA normal-mode rating is the spec I'd anchor any specification conversation to. On commercial security installs where NVRs, PoE switches, and access control panels share branch circuits with HVAC and lighting, you need a suppressor that won't surrender on the first real transient event. The PMP2X-A is built for exactly that environment.

Technical Highlights:

• 80kA Normal-Mode / 40kA Common-Mode: The asymmetric rating — double the normal-mode capacity versus common-mode — reflects real-world surge profiles where line-to-neutral transients are typically the larger threat. Both numbers are well above entry-level suppressor ratings in the 20–40kA range.
• 30dB EMI/RFI Filtering: In practice, 30dB attenuation removes the majority of conducted interference from motor-driven equipment. On a circuit shared with elevator drives or HVAC compressors, this prevents soft failures in IP cameras and NVRs that often get misdiagnosed as firmware or configuration issues.
• -20°C to 70°C Operating Range: Most hardwired suppressors stop at 0°C on the low end. The PMP2X-A's -20°C floor opens up deployment in unheated mechanical spaces, parking structure equipment cabinets, and cold-storage facility control panels without requiring supplemental heating.

Deployment Considerations:

• The 3-wire (2PH + G) input termination is standard for commercial branch circuits, but confirm your panel's available knockout and wire gauge before ordering — the 239 x 74 x 122mm body needs clearance in tight enclosures.
• Non-modular design is the key limitation: when MOV elements reach end-of-life after repeated surge events, the entire unit requires replacement rather than a module swap. For sites with frequent lightning exposure, budget for a periodic replacement cycle and keep a spare unit on the shelf.

For a warehouse automation facility or a multi-building campus security installation where power quality varies significantly across distribution panels, the PMP2X-A's dual-voltage rating and wide temperature tolerance make it a practical hardwired protection layer at each remote equipment enclosure — especially when paired with a UPS on the same circuit for runtime coverage.
