Viking Surface Mount Chassis 5X5 Red - VE-5X5-RD

Viking Electronics VE-5X5-RD Red Surface Mount Enclosure

Overview

The Viking Electronics VE-5X5-RD is a surface mount chassis built specifically for Viking VE-Series doorbox and entry phone installations where visual identification matters — red powder coat makes it immediately distinguishable from standard installations, useful in multi-entry or emergency call station deployments. At 5.22″ × 5.14″ × 3.4″, it provides a compact but serviceable interior for housing Viking entry phone hardware flush against a wall surface without in-wall rough-in.

This enclosure is part of the broader Viking Electronics hardware line, designed to pair directly with Viking VE-Series entry devices. If you're configuring a surface-mounted IP intercom or emergency call station and need the box separate from the device, the VE-5X5-RD ships as a standalone chassis with panel included.

Key Features

• 16-Gauge Cold Rolled Steel Construction (0.062″): Cold rolled steel at this gauge resists casual physical abuse — a deliberate bump, tool contact during adjacent work — without deforming. Thinner-walled enclosures at 20 gauge or higher flex under sustained pressure; 16 gauge holds its shape through normal installation wear and keeps internal hardware seated correctly.
• UV-Stable Red Fine Texture Powder Coat Finish: The powder coat is UV-stabilized, meaning prolonged sun exposure won't cause the red to fade or chalk over time. On exterior-facing or skylight-adjacent installations, standard paints degrade within a season; UV-stable formulations maintain color fidelity for years. The fine texture also hides minor surface scuffs better than a gloss finish would.
• 12-Gauge Aluminum Panel (0.081″): The panel is noticeably thicker than the steel box at 0.081″ and uses aluminum rather than steel — aluminum won't rust if the coating is scratched, which matters in humid or outdoor-adjacent applications. The extra gauge on the panel provides rigidity for mounting hardware without flexing when buttons or devices are pressed repeatedly.
• Clear Gloss Panel Finish: The panel carries a UV-stable clear gloss powder coat rather than a pigmented finish, so engraved or applied text and labeling remain readable. On emergency call or access panels, legibility is a functional requirement, not aesthetic preference.
• Compact 5.22″ × 5.14″ × 3.4″ Footprint: The 3.4″ depth provides enough internal clearance for terminal blocks, short cable runs, and the device PCB without protruding excessively from the wall. At just 2 lbs (0.9 kg) shipping weight, it installs cleanly on standard wall-anchor hardware without requiring structural backing beyond a typical interior stud or masonry anchor.
• VE-LIGHT Kit Compatible: The enclosure is confirmed compatible with Viking's VE-LIGHT LED illumination kit, which adds bright LED lighting to the doorbox front face. If the installation site has poor ambient lighting — underground parking, exterior night use, unlit vestibules — the VE-LIGHT integrates directly into this chassis without modification, avoiding the need for external lighting infrastructure.
• Surface Mount Design — No In-Wall Rough-In Required: Surface mount means the chassis mounts directly to the finished wall face. That eliminates the need to cut a rough-in opening, simplifies retrofit installations in concrete or masonry where cutting is expensive, and keeps cabling fully accessible from the front after removing the panel. For access control retrofits in occupied facilities, this matters: you're not opening walls.

Integration & Compatibility

The VE-5X5-RD is designed for use within the Viking VE-Series product family, which includes entry phones, doorbox stations, and emergency call devices. The 5×5 chassis form factor accommodates Viking's standard VE-Series device footprint. The VE-LIGHT illumination kit is a confirmed compatible accessory for this enclosure size. Installers combining the VE-5X5-RD with a PoE-powered entry phone should route Cat5e/Cat6 through the 3.4″ depth with adequate service loop — the interior is compact but workable with proper cable management.

The red colorway (VE-5X5-RD, often searched as VE 5X5 RD) is a deliberate differentiation from the standard black or stainless enclosures in the VE-Series line. Plan color selection at the design stage — mixing chassis colors across entries in the same facility is rarely intentional and difficult to correct after installation.

Frequently Asked Questions

Q: What is the VE-5X5-RD made of?

A: The box body is 0.062-inch (16-gauge) cold rolled steel with a UV-stable red fine texture powder coat finish. The front panel is 0.081-inch (12-gauge) aluminum with a UV-stable clear gloss powder coat.

Q: What are the dimensions of the VE-5X5-RD enclosure?

A: The enclosure measures 5.22 inches wide × 5.14 inches tall × 3.4 inches deep (133mm × 131mm × 86mm).

Q: Which Viking devices fit inside the VE-5X5-RD?

A: The VE-5X5-RD is part of the Viking VE-Series enclosure line designed to house Viking VE-Series doorbox and entry phone hardware. It also supports the VE-LIGHT LED illumination kit as a confirmed compatible accessory.

Q: Can the VE-LIGHT kit be added to the VE-5X5-RD?

A: Yes. Viking confirms the VE-LIGHT LED illumination kit is compatible with the VE-5x5 enclosure, including the VE-5X5-RD, adding front-face LED lighting without chassis modification.

Q: Is the VE-5X5-RD suitable for outdoor use?

A: The UV-stable powder coat finish is designed to resist sun-related color fading, making it appropriate for installations with sun exposure. However, no ingress protection (IP) rating is specified in the manufacturer evidence — verify environmental suitability with Viking for fully exposed exterior applications before specifying.

Q: Why choose the red VE-5X5-RD over other VE-Series enclosure colors?

A: Red is typically used to distinguish emergency call stations, alarm-associated entry points, or specific access zones in a multi-entry facility. If visual differentiation between entry stations is a design requirement, the VE-5X5-RD provides that without any added hardware.

Karl Wilson

The spec that drives most enclosure decisions on a project like this is depth — and at 3.4 inches, the VE-5X5-RD gives you enough room to work without the box blowing out 5+ inches from the wall face. I've specified the VE-5X5-RD on emergency call station retrofits where the red finish was a code-driven requirement for visual identification, not an aesthetic choice.

Technical Highlights:

• 16-Gauge CRS Box Body (0.062″): This gauge is the practical minimum for a tamper-resistant surface mount enclosure in a public-access environment — thin enough to keep weight at 2 lbs, thick enough that the box doesn't flex when someone leans on it or a cart clips it in a corridor.
• 12-Gauge Aluminum Panel (0.081″): Aluminum at this thickness won't corrode if the clear coat gets scratched during repeated entry use, and the extra rigidity over a thinner panel means push-button hardware stays properly seated over years of operation — important when the device inside handles access decisions.
• UV-Stable Red Powder Coat: UV-stable formulations are a real differentiator from standard powder coat. On a south-facing exterior entry or skylight-adjacent lobby installation, standard red fades within 12–18 months; UV-stable holds color fidelity measurably longer, keeping the visual identification function intact.

Deployment Considerations:

• The 3.4″ interior depth is adequate for Viking VE-Series device hardware and a short cable service loop, but plan your conduit entry point carefully — surface mount means the cable enters from the back or sides of the box, and in masonry installs you'll need to core before setting the enclosure.
• No IP ingress protection rating is published in the manufacturer specification for this enclosure. Don't assume it's rated for driving rain or wash-down environments without confirming with Viking directly — UV-stable finish addresses sun, not moisture intrusion.

The VE-5X5-RD is the right call for emergency call station installations in commercial buildings where visual coding by color is a design or code requirement — lobbies, parking structures, stairwells. For standard entry phone deployments where color differentiation isn't needed, the same VE-5x5 chassis in black or stainless is the more common specification.
