Presentation:
Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
Main Input Voltage:
230 V AC 1 phase
Other Input Voltage:
220 V 240 V
Input Connection:
IEC 320 C20
Efficiency At Full Load:
170...300 V adjustable 180...287 V
Input Frequency:
47...63 Hz
Output Voltage:
230 V AC 1 phase
Rated Power In W:
1300 W
Rated Power In Va:
2000 VA
Output Connection:
6 IEC 320 C13 1 IEC 320 C19
Harmonic Distortion:
Less than 5 % at full load
Maximum Configurable Power In Va:
2000 VA
Maximum Configurable Power In W:
1300 W
UPS Topology:
Line Interactive
Waveform Type:
Sine wave
Output Frequency:
50 Hz sync to mains
Run Time:
View Runtime Graph
Battery Type:
Lead-Acid battery
Control Panel:
Multi-function LCD status and control console
Free Slot:
0
Alarm:
Alarm when on battery : distinctive low battery alarm : configurable delays
Ups Connectivity:
Serial port USB port
Surge Energy Rating:
300 J
Noise Filtering:
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : m
Number Of Rack Unit:
0U
Color:
Gray
Dimensions:
8.5 in (216 mm)
Weight:
60.6 lb(US) (27.5 kg)
Mounting Location:
Front
Mounting Preference:
No preference
Mounting Mode:
Tower
Two Post Mountable:
0
Provided Equipment:
USB cable
Number Of Power Modules:
0
Number Of Power Module Filled Slots:
0
Number Of Power Module Free Slots:
0
Additional Specification:
Entry level
Range Of Product:
Smart-UPS
Product Or Component Type:
Uninterruptible power supply (UPS)
Product Certification:
EAC
Standard:
EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018
Ambient Air Temperature For Storage:
5…113 °F (-15…45 °C)
Storage Altitude:
0…50000 ft (0…15240 m)
Relative Humidity:
0…95 %
Storage Relative Humidity:
0…95 %
Acoustic Level:
45 dBA
Heat Dissipation:
135 Btu/h
Operating Altitude:
0...10000 ft
Extendable Runtime:
0
Included Battery Module:
0
Empty Battery Slot:
0
Typical Recharge Time:
3 h
Rbc Quantity:
1
Battery Life:
3…5 year(s)
Battery Charging Power:
166 W rated
Unit Type Of Package 1:
PCE
Nbr. Of Units In Pkg:
1
Package 1 Height:
13.0 in (33 cm)
Package 1 Width:
23.2 in (59 cm)
Package 1 Length:
14.6 in (37 cm)
Package Weight(Lbs:
66.1 lb(US) (30 kg)
