Middle Atlantic STL Flat 90D. Elbow 700 - V711

Middle Atlantic V711 Steel Flat 90° Elbow Fitting — 700 Series Raceway

Overview

The Middle Atlantic V711 is a flat 90-degree elbow fitting designed for use with the 700-series steel raceway system. At 2.88 in × 2.88 in × 0.88 in, the V711 handles right-angle horizontal direction changes within a surface-mount raceway run — the fitting you reach for when a corridor cable path needs to turn a corner along the same plane without breaking into a separate conduit or junction box. The ivory finish matches the 700-series raceway color family for a clean, uniform appearance in finished commercial interiors. TAA compliance makes this fitting eligible for U.S. federal procurement and government installation projects where domestic sourcing requirements apply.

Compatibility

The V711 is engineered for the Middle Atlantic 700-series flat raceway system. It pairs with the V700 straight raceway sections, V710 flat tee fittings, V712 flat inside corner, V713 flat outside corner, and other V7xx-series components that share the same 700-profile cross-section. This fitting is specific to the flat (surface-mount, low-profile) variant of the 700 line — do not use with the D-line or larger 1000/2000-series cable management products, which use different profile dimensions and fitting families. Confirm your existing raceway carries the V7xx series designation before ordering.

Installation Notes

The flat 90° geometry keeps the elbow flush to the wall surface, so plan your cable bend radius before committing to this fitting — cables with a tight minimum bend radius (e.g., Cat6A or thicker coax) may require a larger-radius sweep elbow rather than a sharp 90° turn. The 0.88 in depth sits within the same profile as the straight V700 sections, so no surface offset or shimming is needed at the joint. Ivory finish; verify your existing raceway run color before ordering if aesthetic matching is a requirement on the project.
