STI KIT-E06402 Exit Stopper Red Reed Switch

Overview

The STI KIT-E06402 is a reed switch exit stopper designed for controlled-access egress points requiring electromagnetic strike engagement at 9VDC. This assembly provides door position feedback through the reed switch mechanism, confirming secure locking engagement during normal operation. Deploy it where you need reliable strike control on single-door or multi-door exit scenarios without complex wiring or auxiliary power infrastructure — the 9VDC requirement keeps integration straightforward on standard access control panels.

Compatibility

The KIT-E06402 integrates with access control systems operating at 9VDC and supporting electromagnetic strike actuation. It is compatible with credential platforms using standard 9VDC powered panels and readers. Verify your panel's strike output voltage (9VDC) and confirm the electrical circuit can source the strike draw before installation. The red color designation indicates the strike type within STI's product lineup — confirm your system documentation references this specific model to avoid ordering incompatible variants.

Installation Notes

Position the strike assembly at the exit door frame, ensuring proper alignment with the latch mechanism. Secure mounting is critical for reliable engagement — use the provided wall fixings and drill pilot holes with a 7mm masonry bit where specified in your installation guide. Wire the strike directly to your 9VDC access control output, observing polarity. For surface-mounted installations, use cable entry gaskets to seal unused holes and protect against environmental ingress. Test locking and unlocking cycles before commissioning to confirm proper strike engagement under load.
