STI STI-6520-C-FR Identification Reader Cover — Clear Polycarbonate
Overview
The STI-6520-C-FR is a clear polycarbonate hinged cover sized for biometric fingerprint readers and integrated keypads in access control installations. It solves a real problem on any high-traffic door or vestibule: readers get smashed, ice-locked in winter, or vandalized. This cover keeps the reader visible and operational while absorbing impact without shattering — it's molded from tough polycarbonate, not cheap acrylic. The French labeling supports multilingual facility requirements. Stainless steel torsion spring holds the cover closed; gasket and mounting screws are included.
Compatibility
Designed for STI biometric and keypad reader families. Compatible with standard access control reader mounting footprints where reader depth and width fall within the cover's interior cavity. Verify your specific reader model dimensions against the cover opening before ordering — covers are model-specific. Works in HID and TCP/IP credential environments where the reader itself manages authentication; the cover is purely mechanical protection.
Installation Notes
Installation is straightforward: drill or use existing anchor points, insert mounting screws (included), and seat the gasket. No special tools required. Gasket should be inspected annually and replaced after five years of exposure to UV and temperature cycling. The cover operates across –40°F to 250°F (–40°C to 121°C), making it suitable for outdoor and harsh indoor environments. Do not force the hinge closed; the torsion spring provides consistent tension. If the cover sticks after six months of weather exposure, clean the hinge pivot with a dry cloth — do not lubricate.
What's in the Box
- 1x STI-6520-C-FR polycarbonate hinged cover (clear)
- 1x stainless steel torsion spring and hinge assembly
- Mounting screws and gasket material
