Middle Atlantic Srsr Extended 23 Space - SRSR-X-23

Middle Atlantic SRSR-X-23 23U Slide-Out Rotating Rack

Overview

The Middle Atlantic SRSR-X-23 is a 23U in-cabinet slide-out rotating rack designed for environments where rear-access to dense equipment stacks is a recurring operational requirement. Rather than pulling or partially dismounting gear to reach cabling, power strips, or rear-panel connections, the SRSR-X-23 lets the entire 23U column slide forward and rotate — keeping technicians out of adjacent aisles and making cable management practical in tight closets and low-ceiling equipment rooms. The rack accepts standard 19-inch equipment on 10-32 threaded rails, with 21.25 inches of usable depth and 40.25 inches of usable height across the 23 RU load space. Weight capacity is 200 lbs (90.7 kg) — enough to support a full complement of NVRs, PoE switches, and patch panels without flex under load. The flat black powder-coat finish resists corrosion and keeps the unit from standing out in finished AV or security equipment rooms. TAA-compliant and manufactured in the USA, making it a straightforward fit for federally funded installations, government facilities, and projects with domestic-sourcing requirements. For integrators building out surveillance system equipment rooms or AV-over-IP infrastructure, the SRSR-X-23 addresses the single most common service complaint in dense rack deployments: you cannot get to the back of the gear once the rack is full.

Compatibility

The SRSR-X-23 accommodates any standard network video recorder, PoE switch, patch panel, or AV processor built to the EIA 19-inch rack standard. Equipment must fit within 21.25 inches of usable depth — verify rear-connector clearance for deep 2U or 3U NVRs before specifying. The 10-32 rack rail threading is the current commercial standard; legacy 12-24 threaded equipment requires a cage-nut adapter (not included). The unit is rated as an in-cabinet rack, meaning it is intended to mount inside an existing enclosure or cabinet structure rather than as a standalone open frame. Pair with a compatible Middle Atlantic enclosure or equivalent cabinet that provides the structural footprint and door clearance the slide-out travel requires. Consult Middle Atlantic's enclosure compatibility matrix to confirm slide clearance before ordering — cabinet interior width and door swing geometry both affect whether the rotation travel is usable in practice.

Installation Notes

Shipping weight is 44 lbs (20 kg) before any equipment is installed — plan for two-person lift and positioning. The overall unit dimensions are 19.13 in wide × 43.25 in tall × 23.14 in deep; confirm rough-in clearance before delivery. The 200 lb weight capacity is the total system load limit — account for the combined weight of all installed equipment, cabling, and power strips when loading the rack. The slide-out and rotation mechanism requires sufficient cabinet door clearance and front-of-cabinet aisle space to complete the rotation arc; measure both dimensions before committing the rack position. For power distribution within the rack, use vertical or horizontal PDUs rated for the installed load and routed to preserve rear-access clearance after rotation.
