Speco Technologies N32WNRN40TB 32-Channel 4K NVR Wall Mount
Overview
The N32WNRN40TB is a 32-channel 4K network video recorder built for wall-mounted deployment in command centers, NOCs, and central stations where control-room footprint matters. It runs H.265 and H.264 codec support across all 32 channels at 4K (3840×2160 @ 30 fps per channel), cutting storage overhead versus H.264 alone — H.265 typically reduces bitrate 40–60% at the same quality, a meaningful factor when feeding 40TB of capacity. The unit measures 15″W × 2.83″H × 13.4″D and weighs 12 lbs, fitting snugly into wall-mount or shallow-rack scenarios. Power draw is 12VDC @ 5A, supplied by an onboard PSU. Quick-discovery wizard for Speco IP cameras and one-click ONVIF integration streamline commissioning across mixed multivendor environments.
Compatibility
The N32WNRN40TB integrates with any ONVIF Profile S–compliant IP camera—including Speco's own Speco IP camera line via plug-and-play discovery. Dual gigabit network ports let you isolate camera traffic from remote-management traffic, critical in large deployments where bandwidth segregation prevents monitoring lag. Recording resolutions auto-scale to 4K on all 32 channels; 16 local audio inputs plus 32 IP audio inputs (G.711 codec) support two-way audio communication. SecureGuard VMS and SecureGuard Mobile apps provide remote access on iOS and Android. Free U.S.-based DDNS and cloud event upload to Google Drive reduce configuration friction in geographically distributed installations.
Installation Notes
Rack ears are included for both wall and shallow-rack mounting. Ensure 12VDC @ 5A power availability at the mount location; no PoE power is supplied by this unit. Cooling airflow across the rear panel is required—do not enclose in an airtight cabinet. The front HDMI, VGA, and CVBS outputs support local monitoring; wire these before final wall positioning. Firmware updates via USB port or network do not require downtime. All configuration is accessible via web browser (PC/MAC compatible) or mobile app; no proprietary software installation needed on client machines.
What's in the Box
- 1x N32WNRN40TB NVR (wall-mounted form factor)
- 1x Set of rack ears
- 1x 12VDC power supply
- 1x Front panel overlay
