Speco Technologies H24WHRN8TB 24-Channel Wall-Mount Hybrid Recorder
Overview
The H24WHRN8TB is a wall-mounted hybrid video recorder designed for mixed analog and IP deployments across 24 total channels. It combines 16 hybrid-capable channels (accepting TVI or IP input per channel) plus 8 dedicated IP channels, making it a practical choice for integrators managing staged upgrades from analog-only sites or retrofits that blend legacy and new camera infrastructure. With 8TB onboard storage, H.265 compression, and direct IP camera discovery, it handles the storage arithmetic of continuous recording across heterogeneous systems—H.265 delivers roughly 2x the recorded duration compared to H.264 at the same bitrate, a material difference when budgeting storage for 24-channel continuous operation.
Compatibility
The H24WHRN8TB accepts Speco IP cameras across supported resolutions (5MP Lite, 4MP Lite, 1080P, 1080P Lite, 720P, WD1, D1) and TVI analog sources (960H and earlier). Smart Analytics features integrate with Speco Smart Analytic IP cameras, enabling edge-based object detection and line-crossing alerts at the camera. The unit includes EZ Wizards for camera auto-discovery and quick network setup, reducing integration time on mixed-source installs. It does not function as a standalone recorder for non-Speco camera brands—compatibility is limited to Speco's camera ecosystem and TVI sources.
Installation Notes
Wall-mount installation suits control rooms, network closets, and technical spaces where rack depth is unavailable or accessibility is needed at arm's reach. The unit draws DC 12V/2A and includes one RJ-45 100Mbps network interface for configuration and remote access. Two SATA ports support up to 28TB total internal storage (the 8TB variant includes one or two drives depending on configuration); one eSATA port allows external storage expansion up to 8TB for archive or offsite backup. Simultaneous HDMI and VGA outputs support dual-monitor setups. Two-way audio via speaker enables remote communication during live monitoring or playback. No torque or environmental constraints are documented in available evidence.
What's in the Box
Package contents not specified in manufacturer documentation.
