Vertiv 29048 Metered Surge Power Distribution Unit

Overview

The Vertiv 29048 is a 1U rack-mount metered surge PDU designed for environments where facility-level surge suppression is absent or where additional protection is required. This horizontal-mounting unit combines built-in surge protection with a real-time power monitoring display, making it suitable for critical server and surveillance deployments where you need both equipment protection and visibility into power draw.

Key Features

• 10 NEMA 5-15R Outlets: Provides ten standard 15A receptacles per outlet, eliminating the need for additional power strips and reducing cable clutter in rack environments. Each outlet receives the same surge-protected power delivery.
• Built-In Surge Protection: Delivers reliable power to critical IT equipment within a rack or cabinet without requiring a separate surge suppression device upstream. This is essential when your facility power conditioning is uncertain or when you are deploying equipment to a temporary location.
• Local LED Power Meter Display: Real-time power consumption metrics are displayed on the unit itself, giving instant feedback during equipment deployment or when moving critical servers and surveillance recorders. No need to pull data from network management systems — visual wattage confirmation is available at the cabinet.
• 15A Maximum Current at 120V Input: Operates within standard 120V household and light commercial power circuits (100–120V input range, 50/60 Hz compatible). The 15A limit means you can safely deploy this PDU on a standard 15A circuit breaker without tripping, reducing facility coordination overhead.
• Extended 10-Foot Cable: 120.1-inch (3.05 m) power cord provides flexibility in cabinet placement and reduces the need for extension cords or reposition of wall outlets. Longer reach is particularly useful in retrofits where the nearest outlet is not directly behind the equipment rack.
• UL and c-UL Listed (60950); RoHS Compliant: Meets North American safety standards and environmental compliance requirements, reducing liability risk when deploying in regulated environments (healthcare, government, critical infrastructure). No additional certification review is required for most facility acceptance.

Integration & Compatibility

The model 29048 integrates into any standard 19-inch rack that accepts 1U devices. Its horizontal mounting orientation means it occupies a single rack unit and can be positioned at the bottom, middle, or top of a cabinet depending on cable routing needs. The NEMA 5-15R outlets are universal, accepting any standard US-market power cord, making it compatible with legacy and current surveillance NVRs, IP cameras with external adapters, network switches, and server equipment. No proprietary connectors or adapters are required.

What's in the Box

The Vertiv 29048 ships with the unit itself and the 120.1-inch power cord with NEMA 5-15P plug. No additional mounting hardware, brackets, or cabling is included — the PDU is designed to fit standard rack rails without supplemental components.

Frequently Asked Questions

Q: Does the Vertiv 29048 require network connectivity or software to function?

A: No. The local LED display provides power metrics without any network link. This is a passive surge protection and metered power device — it requires only AC power input to operate.

Q: Can the 29048 protect against lightning strikes or utility surges?

A: The unit provides surge suppression for transient overvoltages on the AC line. It is not a substitute for facility-level surge arresters or lightning protection. Use it as an additional layer of protection for critical equipment, not as your primary surge defense.

Q: What is the warranty period on the Vertiv 29048?

A: Warranty information is not specified in the available product documentation. Contact the manufacturer or your reseller for warranty terms and coverage details.

Q: Is the power meter display backlit or visible in low-light rack environments?

A: The product documentation does not specify display backlighting. Ensure adequate cabinet lighting when reading the LED display, or plan for periodic visual checks during daylight hours.

Q: Can I daisy-chain multiple Vertiv 29048 units on the same circuit?

A: Each unit draws up to 15A at 120V. Verify your facility breaker capacity before connecting multiple PDUs to the same circuit. Most standard 15A circuits can safely support only one 15A load; exceeding circuit capacity will trip the breaker.

Q: Is the 29048 suitable for outdoor or non-climate-controlled environments?

A: The product documentation does not specify operating temperature limits or environmental ratings for outdoor exposure. This unit is designed for indoor, climate-controlled rack environments. Do not expose it to rain, extreme heat, or freezing temperatures without additional environmental enclosure.

Ted Perry

I've deployed the Vertiv 29048 in surveillance control rooms where the facility power drop is shared across multiple systems and facility surge protection is either non-existent or inadequate. The local LED display on the 29048 is a real differentiator — you get instant visibility into rack power draw without logging into a remote management system. On the model 29048, that display updates in real time, so when you're commissioning a new NVR or moving a camera power supply, you can confirm the load hasn't spiked unexpectedly.

Technical Highlights:

• 10 NEMA 5-15R Outlets with Surge Protection: Each outlet is independently protected, meaning a transient spike on one circuit won't degrade protection for the others. In surveillance deployments with multiple camera PoE injectors and NVR equipment, this isolation is valuable when you're running multiple independent power chains.
• 15A Maximum at 120V, 50/60 Hz: Stays within the thermal and safety envelope of standard household circuits. You won't need to negotiate a dedicated 20A circuit with facility management — the 29048 integrates into existing light commercial wiring without resistance.
• 120.1-Inch Power Cord (3.05 m): Solves a real retrofit problem. In many surveillance installations, the nearest wall outlet is 8–10 feet away from the equipment rack. The long cord eliminates the need for extension cords or multiple power strips, both of which add failure points and clutter.

Deployment Considerations:

• The surge suppression is reactive — it handles transients and overvoltages but does not condition input voltage or provide UPS functionality. If your facility power is unstable (sags, brownouts), pair the 29048 with an upstream UPS for continuous protection during power events.
• The 15A limit is firm. If you load all 10 outlets with maximum-draw devices (e.g., 1.5A each), you'll approach or exceed 15A total. Plan your outlet allocation carefully — don't assume you can power 10 full devices simultaneously without checking total wattage and available branch circuit capacity.

The Vertiv 29048 is the right choice for multi-camera surveillance installations where you need metered power distribution and surge protection in a compact 1U form. If you're upgrading from an unprotected power strip to a rack-mounted solution, the local power display and surge isolation will pay for itself the first time a transient event would have tripped an unprotected outlet.
