Panduit FY9TP77Y006F030 12-Fiber Singlemode Pre-Terminated Trunk Cable
Overview
The Panduit FY9TP77Y006F030 is a 30-foot (9.1m) singlemode, 12-fiber pre-terminated trunk cable from the Panduit QuickNet HD Flex sub-brand. Designed for fiber optic trunk infrastructure in data centers, telecom rooms, entrance facilities, and equipment distribution areas, it delivers a plug-and-play interconnect that eliminates field splicing and dramatically cuts installation time. Pre-terminated trunks like this are the backbone of modern high-density fiber deployments where structured installation speed and repeatability matter.
Key Features
- Pre-Terminated, Field-Ready: Factory-terminated connectors mean zero field splicing — installers route and connect rather than prep, splice, and test. On a data center floor where each technician-hour is expensive, that difference compounds across dozens of runs.
- 12-Fiber Count: Twelve fibers per trunk supports parallel 10G, 40G, or 100G breakout topologies depending on the connector interface. Sized for mid-density interconnects between patch panels, switches, and distribution frames without running multiple smaller assemblies.
- Singlemode Fiber: Singlemode glass supports long-reach and inter-building runs where multimode falls short. If your backbone spans multiple floors or buildings, singlemode eliminates the distance ceiling that OM3/OM4 multimode imposes — typically a hard limit at 300–550m for 10G.
- 30ft (9.1m) Length: The FY9TP77Y006F030's 9.1-meter run covers top-of-rack to end-of-row or mid-row aggregation switches without slack management headaches. Exact pre-cut lengths keep cable trays cleaner than field-cut alternatives.
- QuickNet HD Flex Construction: The HD Flex design is built for high-density structured cabling environments where bend radius, pull tension, and routing flexibility are daily constraints. Trunk construction keeps individual fibers protected in a single jacketed assembly rather than loose tubes that fray during installation.
- Data Center and Telecom Room Validated Application: Panduit explicitly rates this assembly for data centers, telecom rooms, entrance facilities, and equipment distribution areas — the full range of structured cabling topology points where pre-terminated trunks are the standard approach.
Integration and Compatibility
The FY9TP77Y006F030 integrates with Panduit's QuickNet HD Flex ecosystem of panels, cassettes, and enclosures. Verify connector interface compatibility (LC, MTP/MPO, or other) with your existing or planned fiber patch panels before ordering — trunk connector type must match the panel's adapter interface. Singlemode transceivers and optics at each endpoint are required; this assembly does not support multimode-only optics.
Frequently Asked Questions
Q: What connector type does the FY9TP77Y006F030 use?
A: The source evidence does not specify the connector interface. Contact pre-sales to confirm whether this trunk terminates in LC, MTP, MPO, or another interface before ordering.
Q: Is this cable rated for singlemode or multimode fiber?
A: Singlemode. The FY9TP77Y006F030 uses singlemode glass, making it suitable for long-reach and inter-building backbone runs where multimode distance limits are a constraint.
Q: What environments is this trunk assembly rated for?
A: Panduit specifies data centers, telecommunications rooms, entrance facilities, and equipment distribution areas as the intended application environments.
Q: Can I use this trunk for 40G or 100G applications?
A: The 12-fiber count and singlemode construction support breakout topologies used in 40G and 100G architectures, but the specific transceiver and panel configuration at each end determines actual throughput capability. Verify your optics and panel compatibility.
Q: What is the exact length of the FY9TP77Y006F030?
A: 30 feet (9.1 meters) overall length, factory-terminated — no field cutting or splicing required.
The FY9TP77Y006F030 is one of those assemblies that earns its keep the moment you compare installation labor against a field-terminated alternative. At 30 feet (9.1m) with 12 singlemode fibers pre-terminated at the factory, this QuickNet HD Flex trunk cuts the pull-terminate-test cycle to a simple route-and-connect. On a 50-run data center backbone project, that difference can recover a full day of technician time.
Technical Highlights:
- 30ft Factory-Terminated Length: The 9.1m pre-cut length targets top-of-rack to end-of-row aggregation runs — long enough to cross a mid-size rack row without slack management issues, short enough to keep cable trays clean.
- 12-Fiber Singlemode Construction: Twelve SM fibers in a single trunk jacket handle parallel 10G, 40G, or 100G breakout topologies. Singlemode glass removes the distance ceiling that OM3/OM4 imposes, which matters the moment you're spanning floors or campus buildings.
- QuickNet HD Flex Sub-Brand: The HD Flex series is engineered for high-density environments where bend radius and pull tension during installation are real constraints — not just spec-sheet considerations.
Deployment Considerations:
- Confirm the connector interface type (LC, MTP, MPO, or other) matches your panel and cassette adapters before the assembly ships — the evidence doesn't specify connector type, and a mismatch on a pre-terminated trunk is not a field fix.
- Singlemode-only: ensure all transceivers and optics at both endpoints are singlemode-compatible. Mixing multimode optics on an SM trunk produces signal loss that won't always show up as a hard link failure — just degraded performance that's painful to diagnose.
The FY9TP77Y006F030 is the right call for structured data center backbone deployments — specifically inter-row or inter-cabinet singlemode runs in a Panduit QuickNet HD Flex panel environment where installation speed and fiber density both matter.
