Vertiv SC68442 Side CAR Rack Enclosure Column
Overview
The Vertiv SC68442 is an 84-inch-tall, 6-inch-wide, 42-inch-deep side column (Side CAR) designed to extend or close out compatible Vertiv ES-series rack enclosures. If you're building out a structured server rack row or adding a finishing side panel to an existing ES enclosure, this is the part that closes the gap — literally. The SC68442 is sized specifically for 84"H × 42"D ES enclosures, so verify your existing rack depth and height before ordering.
Compatibility
The SC68442 is verified compatible with the following Vertiv ES enclosure models at the 84"H × 42"D configuration:
- SC128442: 84″H × 42″D ES enclosure
- SC68442: 84″H × 42″D ES (this unit's own family)
- SCP8442: 84″H × 42″D ES enclosure
Side CAR units are also available for adjacent ES sizes — 79"H × 42"D, 84"H × 48"D, 91"H × 42"D, and 91"H × 48"D — so if your row mixes enclosure heights or depths, confirm the correct Side CAR part number per enclosure. The Vertiv rack and enclosure line uses consistent mounting geometry across the ES family, but a 42"D Side CAR will not fit a 48"D enclosure.
For cable management accessories that pair with ES enclosures, the LRB-12, LRB-12A1, LRB-12A2, LRB-24, LRB-24A1, and LRB-24A2 cable management brackets are listed as compatible across all ES sizes and can be used alongside this Side CAR installation.
Installation Notes
The SC68442 installs as a structural side element of the ES rack row — it provides a finished edge and physical closure for the enclosure footprint. At 6 inches wide and 42 inches deep, it matches the depth profile of the 84"H × 42"D ES host enclosure exactly. Confirm floor-to-ceiling clearance (84" = 7 feet) and row alignment before installing in a raised-floor data center or equipment room. This is a passive structural component — no power, cabling, or configuration required.
Frequently Asked Questions
Q: Which Vertiv enclosures is the SC68442 compatible with?
A: The SC68442 is verified compatible with 84"H × 42"D ES enclosures: SC128442, SC68442, and SCP8442. It is not listed as compatible with 48"D or 79"H or 91"H variants — those require their own corresponding Side CAR part numbers.
Q: What are the physical dimensions of the SC68442?
A: The SC68442 measures 84 inches tall × 6 inches wide × 42 inches deep.
Q: Is the SC68442 compatible with Vertiv cable management accessories?
A: Yes. The LRB-12, LRB-12A1, LRB-12A2, LRB-24, LRB-24A1, and LRB-24A2 cable management brackets are listed as compatible with all ES sizes and can be used in conjunction with this Side CAR.
Q: Does the SC68442 require any tools or power to install?
A: The SC68442 is a passive structural component — no power connection or configuration is required. Installation is mechanical, attaching to the ES enclosure frame. Refer to Vertiv installation documentation for the ES series for fastener and alignment details.
The SC68442 is a depth-specific part — the 42-inch depth is not interchangeable with the 48-inch Side CAR variants in the same Vertiv ES family, and that distinction catches integrators off guard when ordering row closeout hardware for mixed-depth deployments.
Technical Highlights:
- 84"H × 42"D Profile: matches the exact footprint of SC128442, SC68442, and SCP8442 ES enclosures — no shimming or custom fabrication required for a flush row finish.
- 6-Inch Width: a standard side column dimension for ES-series row builds; accounts for structural framing without consuming usable rack unit space inside the enclosure.
- LRB Series Compatibility: the full LRB-12/LRB-24 cable management bracket family is listed as compatible across all ES sizes, so existing cable management investments carry over when adding this Side CAR to an existing row.
Deployment Considerations:
- Confirm enclosure depth before ordering — the SC68442 is a 42"D part; the equivalent 48"D Side CAR (SC68448) is a separate SKU and the two are not interchangeable.
- At 84 inches tall (7 feet), verify overhead clearance in the equipment room before placing the row configuration — raised-floor environments with low overhead cable trays are the most common fit issue.
The SC68442 is the right call when closing out a structured ES enclosure row at the 84"H × 42"D standard in a purpose-built equipment room or data center colocation cage where a finished, flush row edge matters for airflow containment and physical security.
