Vertiv MPUIQ-VMCHS-G01 Server Interface Module
Overview
The Vertiv MPUIQ-VMCHS-G01 is a Server Interface Module (SIM) designed to provide essential connectivity for remote server management. It bridges the gap between a server's internal ports and external KVM (Keyboard, Video, Mouse) consoles, crucially supporting USB virtual media functionality. This allows administrators to remotely access and manage servers as if they were physically present, facilitating OS installations, firmware updates, and diagnostics without requiring on-site intervention. The MPUIQ-VMCHS-G01 is specifically suited for deployments requiring VGA video output.
Compatibility
This Server Interface Module is compatible with Vertiv's MPU (Modular Port Unit) series appliances. It is designed to work with servers that present standard VGA video signals and PS/2 or USB keyboard/mouse inputs. While specific server models are not listed, its function as a SIM implies integration with enterprise-grade server hardware that supports this type of remote management interface.
Installation Notes
Installation involves connecting the module to the server's internal video and USB ports using the appropriate cables (typically included with the server or KVM switch). The module then connects to the external KVM console via VGA and USB cables. Ensure proper cable management to avoid strain on the server's internal connectors. The module requires a USB host connection for virtual media functionality, which is standard on most modern servers.
