i-PRO MX-O-SMA-S-6D079 SMA Sensor Module S16/M16 S15/M15
The i-PRO MX-O-SMA-S-6D079 is a replacement sensor module designed for integration into i-PRO's S16/M16 and S15/M15 modular camera platforms. This SMA-connector sensor element enables camera refresh without full head replacement, reducing lifecycle costs on existing deployments. The module delivers HD-grade image capture and integrates seamlessly into the i-PRO modular architecture, making it an economical path to sensor upgrade or repair across multi-camera installations.
Key Features
- SMA Connector Interface: Hot-pluggable SMA connector design — no soldering, field rewiring, or mechanical rework required. Power and video signals pass through the connector interface.
- S16/M16 and S15/M15 Compatibility: Direct-fit replacement for specified i-PRO modular camera generations. Connector pinout and mechanical form factor are platform-specific; verify your camera revision before ordering.
- HD Image Capture: Delivers HD-resolution output suitable for indoor and controlled-environment surveillance. Pairs with your existing i-PRO camera body, optics, and recording infrastructure.
- Modular Design: Enables targeted sensor refresh without replacing the entire camera head, extending equipment service life and reducing capex on mature installations.
- ESD-Protected Element: Sensor assembly is safeguarded against electrostatic discharge — handle by connector body only, avoiding direct contact with sensor surface.
- No Field Modifications: Plug-and-play installation — power down the camera, disconnect the old module, insert the new module via SMA connector, and power up. No firmware flashing, driver installation, or lens recalibration needed.
The modular sensor approach is common in professional surveillance deployments where camera bodies remain in service for extended periods but imaging sensors degrade, become obsolete, or require refresh to meet new resolution or low-light performance standards. By decoupling the sensor from the housing, i-PRO allows integrators to upgrade legacy systems without replacing structural mounts, cable runs, or power delivery infrastructure.
This module is sourced as a factory-new genuine i-PRO part. Before ordering, confirm your installed camera body is a compatible S16, M16, S15, or M15 model and that your unit uses the SMA connector revision — some production batches of these platforms shipped with alternate connector types. i-PRO technical documentation or your system documentation will list the connector type; mismatched connectors will not mate.
Installation is straightforward but requires a powered-down camera to avoid transient voltage on the connector pins. Once installed, the module operates under the same IP addressing, video codec, and recording policies as the rest of your camera — no additional configuration or VMS changes are needed. If you are integrating this into a Milestone Integrated Client, Genetec Security Center, or other ONVIF-compliant platform, the camera firmware will auto-detect the new sensor on next boot and stream standard RTSP/MJPEG feeds without intervention.
The i-PRO modular ecosystem is purpose-built for environments where sensor refresh cycles differ from mechanical refresh cycles — particularly useful in retail, warehouse, and facilities management deployments where the installed camera base is stable but imaging requirements evolve. This module is the direct-fit replacement part for that use case; if you require a different connector type (such as legacy parallel I/O or proprietary connectors), consult the full i-PRO modular catalog.
Marty AllisonPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
We've deployed a lot of i-PRO modular platforms across retail chains and light-industrial facilities, and the value of the sensor-swap approach becomes clear once you're past year three of a camera's lifecycle. The MX-O-SMA-S-6D079 is a straightforward drop-in replacement for aging or failed sensors in the S16/M16 and S15/M15 lines. In practice, this eliminates the capex trauma of full camera refresh and the operational friction of swapping housings, running new cable runs, and recertifying mount integrity. You power down, swap the module, power up, and you're back to HD capture — no firmware updates, no VMS reconfiguration, no call to your integrator. That said, the critical gate here is connector revision. We've seen field orders slip because a customer assumed their S16 had the SMA version when production data showed they got the parallel connector batch from 2018. Before placing an order, pull your camera's serial number and check i-PRO's compatibility matrix or reach out to pre-sales. A wrong connector order is a wasted shipping cycle.
Technical Highlights:
- SMA Connector Mechanical: The SMA interface handles power and video signaling without field soldering. The connector is keyed to prevent reverse insertion, but the mating force is precise — overtightening on installation can crack the module's connector body. Hand-tighten only; torque specs are in the i-PRO install guide if you have a torque-sensitive deployment (e.g., vibration-prone outdoor enclosures).
- HD Sensor Resolution and Output: Module delivers HD-grade image data to the camera body's processing chain. The i-PRO S/M platform handles codec selection and bitrate control at the head level, so video quality and compression are governed by your NVR recording policy, not the module itself. Expect standard MJPEG or H.264 output depending on your firmware version.
- Modular Refresh Economics: Typical sensor replacement extends camera service life 3-5 years at 30-40% of full-camera cost. If you have a fleet of 20 cameras on a 7-year lifecycle, one sensor failure per year justifies keeping spare modules in inventory rather than staging full replacement units.
- ESD and Handling: The sensor array is sensitive to static discharge. Always ground yourself before handling, and store the module in anti-static packaging. If you're doing high-volume swaps (e.g., refresh a 50-camera install in a single weekend), use an ESD wrist strap and mat — one accidental zap voids the module.
- No Firmware Interaction: The module is purely a passive optical and sensor element. Camera firmware does not need updates to recognize it, and you cannot configure or monitor the module directly — all imaging parameters are set at the camera or NVR level.
Deployment Considerations:
- Connector Revision Verification: The SMA variant is not the only connector option for S16/M16 and S15/M15 platforms. Confirm your camera body is documented as SMA-equipped before ordering. Check the camera's label, serial-number documentation, or contact i-PRO for clarification. A mismatched connector is a non-starter.
- Power-Down Requirement: Always power down the camera before removing or inserting the module. Hot-swapping can induce transient voltage spikes that damage the module's circuitry or the camera body's mating interface. A 10-second shutdown is a small price for avoiding a module or head replacement.
- Spares and Inventory: If you support a fleet of 15+ modular i-PRO cameras, keep at least one spare sensor module in stock. Sensor failure is often the first component to age in a surveillance system, and having a swap unit on hand eliminates unplanned downtime. Storage should be static-safe and climate-controlled (standard office environment is fine).
- Integration Platform Agnostic: The module works with Milestone Integrated Client, Genetec Security Center, Avigilon Control Center, and any ONVIF-compliant NVR. No VMS-specific firmware or licensing is required — the camera firmware handles standard RTSP/MJPEG streaming once the module is seated.
- Long-Term Availability: i-PRO has historically maintained spare-parts availability for modular platforms across 7-10 year horizons, so if you're building a refresh rotation into your maintenance plan, the module should remain available for the camera's full service life. However, component obsolescence does happen — confirm availability with your distributor if you're planning spares purchases for years 5-7 of a deployment.
This module is the right choice if you own a S16/M16 or S15/M15 fleet and need targeted sensor refresh without full camera replacement. It's economical, straightforward to install, and integrates seamlessly with your existing recording infrastructure. For the full modular platform catalog and compatibility matrix, see the i-PRO catalog.
