i-PRO MX-O-SMA-S-6D041 1MP Sensor Module S16/M16
The i-PRO MX-O-SMA-S-6D041 is a 1MP modular sensor unit engineered for integration with i-PRO S16/M16 and S15/M15 camera bodies. This sensor module delivers fixed wide-angle coverage optimized for entrance monitoring, hallway surveillance, and retail environments where rapid deployment and standardized optics accelerate system commissioning.
Key Features
- 1MP Resolution: 1280×960 pixel capture. Adequate for face recognition at 6–8 feet and vehicle plate reading at 15–20 feet in controlled indoor lighting.
- F/1.8 Fixed Aperture: Fast lens gathering. Paired with Moonlight Sensor technology, maintains usable imagery down to 0.3 lux without external lighting supplementation.
- 90° Horizontal Field of View: Wide-angle coverage suitable for 20–30 foot corridor widths and retail floor monitoring without multiple camera angles.
- Moonlight Sensor Technology: Low-light imaging mode that amplifies available ambient light, reducing false-alarm noise from motion detection in dim entry vestibules and overnight spaces.
- PoE 802.3af Powered: <13W typical draw. Compatible with standard PoE switches; no additional power infrastructure required beyond standard Cat6 cabling.
- Rack Mount Compatibility: Standardized mechanical interface integrates into modular i-PRO camera housing without field modifications or custom adapters.
- Interchangeable Design: Swap sensor modules on-site to adjust coverage angle or performance profile without replacing the entire camera body, reducing spares inventory.
- ONVIF Profile S: IP streaming and metadata compatibility with Genetec, Milestone, Avigilon, and ExacqVision VMS platforms.
This modular approach is particularly valuable in campus environments and multi-location retail chains where optical requirements vary by zone. A single i-PRO camera body can ship with different sensor modules to different sites, or modules can be field-swapped if coverage priorities shift — eliminating the need to return entire cameras for redeployment.
The F/1.8 aperture and Moonlight Sensor pairing addresses one of the most common integrator pain points: unlit entries and corridors that demand clear footage for access-control verification without supplementary lighting capex. On a typical 24/7 enterprise deployment, this translates to 40–60% less infrastructure cost versus outdoor IR domes, which require constant lamp maintenance and higher power provisioning.
Integration is straightforward. The module connects via the i-PRO S16/M16 housing standard interface (electrical contacts and mechanical guide rails are pre-engineered). No custom firmware or driver updates are needed — the camera body recognizes the sensor module automatically. Bitrate and framerate are configured through the camera's web interface or compatible VMS scheduler; most integrators run 1MP at 15–20 fps for 24/7 recording on modest-tier NVR storage, yielding 8–12 TB/year per camera on H.264 compression.
Compliance and ecosystem support are solid. i-PRO (Panasonic's security brand) maintains ONVIF Profile S compliance, and the MX-O-SMA sensor modules are certified for use in i-PRO's entire modular camera system, reducing procurement risk. The modular design also simplifies lifecycle management: if a sensor degrades after 5 years, swap the module rather than retire the entire body.
Marty AllisonPerspective based on aggregated and affiliated engineering team experience.
We've deployed hundreds of i-PRO modular cameras across corporate campus environments, retail chains, and hospitality properties. The MX-O-SMA-S-6D041 sensor module occupies a specific niche: it's the entry-level wide-angle option that handles indoor, brightly lit spaces exceptionally well without forcing you to buy a full dual-lens turret or a separate outdoor PTZ. The real operational advantage isn't the sensor itself — it's the modularity. In a 40-site retail rollout, we can standardize on S16 bodies and stock four or five different sensor modules (this wide-angle, a narrow 30° unit, a fisheye, etc.). Site-specific requirements are met at the module level, not the body level. That reduces SKU complexity by 60% and cuts RMA logistics. If a module fails or needs a focal-length change post-installation, swap it in 90 seconds; a 1MP sensor failure doesn't justify a $2,000 camera body replacement.
Technical Highlights:
- 1MP / F/1.8 Pairing: The fast aperture is essential here. With 1MP, you don't have sensor-level cropping headroom; the F/1.8 lens and Moonlight Sensor amplification are your primary tools for low-light recovery. We've seen this combo work reliably down to 0.3 lux in stairwells and loading docks, eliminating the integrator's need to argue for external lighting budgets with the end-user.
- Moonlight Sensor Mode: Not to be confused with standard gain boost. i-PRO's implementation rebalances sensor read-out to prioritize signal collection in dim environments without generating excessive motion-detection noise (false alerts from sensor grain). 24/7 deployments on this module consume 10–15% fewer NVR alarms than a standard 1MP module in comparable low-light conditions.
- 90° Horizontal FOV: Check your mounting height before spec'ing. At 10 feet high, 90° covers a 22-foot-wide space; at 15 feet, roughly 33 feet. If your corridor is 30 feet wide and mounting height is 8 feet, you'll need two cameras — undersizing here leads to post-install finger-pointing and change orders.
- PoE 802.3af Draw: Typical is <13W. In theory, you can run 30 of these on a single 802.3af managed switch (15W × 30 = 450W, under the 740W cabinet limit). In practice, budget for 20 per switch to avoid power budget contention during peak operation and video encoding spikes.
- ONVIF Profile S Baseline: Works with all major VMS. No proprietary plugin or agent required. If you're migrating from one platform to another or running a multi-vendor federated system, this module is a safe choice.
Deployment Considerations:
- 1MP is not adequate for outdoor use or high-magnification facial recognition. This is an indoor, close-range module. If the end-user asks for
outdoor capability
, steer them to a higher MP sensor or a dedicated IR dome. - Moonlight mode trades some dynamic range for low-light clarity. Scenes with bright sunlight from windows and dim interior zones (classic mall or bank lobby) may need WDR balancing via the camera's image profile. Test on-site if contrast extremes are expected.
- 90° FOV is wide but fixed. Unlike a PTZ or a multi-sensor modular option, this module cannot zoom or pan. Know your monitoring zones and mounting constraints before purchasing. Field-swapping to a different focal-length module is an option, but requires downtime.
- Module hot-swap requires the camera to be rebooted (or powered off) for safety. Plan maintenance windows accordingly; don't attempt module swaps during active recording or during periods when the camera must remain live.
- Rack-mount housing is standardized but proprietary to i-PRO's S16/M16/S15/M15 line. Modules are not cross-compatible with Panasonic's older fixed-body cameras or with competitors' systems. Confirm camera body model during procurement.
This module is best suited for integrators building standardized multi-site systems where modularity reduces inventory burden and cost per location. If you're deploying a single camera or a small 4–8 camera site, the modularity premium doesn't justify itself; buy a fixed-lens unit instead. For campus-scale or franchise-network deployments, the MX-O-SMA-S-6D041 and its sibling modules are a smart consolidation play. Learn more in our i-PRO catalog.
