SDC 463NU Integrated 1-30 Sec Timer Lock/Strike

We've deployed the SDC 463NU across a range of environments—retail stockrooms, pharmaceutical manufacturing floors, data center secure corridors—and consistently found the single-unit design to be a time-saver on commissioning. The killer benefit is the on-board timer potentiometer. On legacy systems with external timer modules (often buried in a distribution cabinet 50+ feet from the door), adjusting timed release meant a site visit with a technician carrying a multimeter. With the 463NU, the timer dial is right there on the device. A facilities tech can dial in the hold time in real-time while watching the door strike engagement. We've reduced timed-release tuning cycles from 2-3 hours down to 15 minutes on typical door retrofits. The OSDP native protocol is the differentiator that justifies spec'ing it over older proximity-only strikers—you avoid vendor lock-in and future-proof the installation against protocol sunsetting. On a 50-door campus upgrade, that standardization translates to a single spares inventory, unified training, and faster second-source component swaps if a manufacturer discontinues a proprietary reader. The one caveat: the 1-amp contact rating is real. We've seen integrators assume they can wire an oversized fail-safe strike directly to the output and then wonder why the unit chatters or de-rates under load. A relay buffer costs $30 and eliminates that risk—always measure the strike coil draw at commissioning.

Technical Highlights:

• OSDP Native Protocol: Eliminates gateway dependency and vendor proprietary encoding. Direct integration with any OSDP-certified access control panel—Genetec, Salto, Gallagher, Lenel all support this out of the box. Reduces capex on protocol converters and wiring complexity.
• Adjustable 1–30 Second Timer: Field-tunable via potentiometer—no software reprogramming, no panel re-entry required. Turn the dial, test the door, dial again if needed. Crucial for facilities with variable egress speed (e.g., wheelchair-accessible entries require longer hold times than standard throughways).
• Dual Credential Input (Proximity + Keypad): Single device accepts both NFC/13.56MHz cards and PIN entry. Useful for hybrid workflows: badge for fast egress, keypad for after-hours manual override or visitor access without card enrollment.
• 30VDC Supply: Standard access control voltage. Aligns with most distributed door controllers and power supplies—no boost modules or voltage regulation required, simplifying BoM and reducing failure points.
• Shallow Depth (1 1/8 inches): Fits standard door frame strike cavities without frame modification. On retrofits, this eliminates frame carpentry and reduces project scope—install the device, wire it, done.
• SPDT Output with 1-Amp Rating: Sufficient for standard electromagnetic strikes. Pair with a relay if coil draw exceeds 1 amp. The relay isolation also protects the device from inductive kick-back on strike de-energization.

Deployment Considerations:

• Verify your access control panel outputs 30VDC and can source 150+ mA continuously. Legacy 24VDC-only systems require a boost module—budget $50–150 for external 24-to-30VDC converter if needed.
• Measure strike coil current with a clamp meter at 30VDC before final installation. If draw exceeds 1 amp, add a 24VDC or 12VDC relay in parallel—the 463NU output triggers the relay coil, which handles the heavier load. This is standard practice on fail-safe or dual-coil strikes.
• Install the timer dial in an accessible location. If surface-mounting, locate it where facilities staff can turn the potentiometer without disassembling door hardware. Interior-mounted units (in the frame cavity) are not field-adjustable without door removal.
• Confirm OSDP Reader output support on your access control panel before ordering. Older systems (pre-2015) may run Wiegand or RS-485 only. A quick spec review with your panel vendor prevents integration surprises.
• Test the timer under load during commissioning. Run a full egress cycle (badge or PIN, door unlock, manual push) and verify the strike holds for the dialed-in duration. If the door releases prematurely, check for coil-load mismatch or wiring polarity issues.

The SDC 463NU is the right choice for integrators and end-users moving toward open-protocol, vendor-neutral access control infrastructure. On multi-door deployments and retrofits where standardization and simplicity matter, it eliminates integration overhead and reduces field-support burden. Explore the full SDC catalog for complementary reader and strike hardware.
