SATO CL4NX Plus 203dpi Industrial Thermal Printer - WWCLP1001-NMR

SATO CL4NX Plus 203dpi Industrial Thermal Transfer Printer – WWCLP1001-NMR

The SATO WWCLP1001-NMR is a high-performance industrial thermal transfer printer engineered for demanding enterprise labeling environments. Built on the proven CL4NX Plus platform, this printer delivers professional-grade output at 203 dpi resolution with print speeds up to 14 ips, making it ideal for high-volume production workflows in logistics, manufacturing, and warehouse operations. The robust cast aluminum frame with corrosion-resistant materials ensures reliability in challenging industrial settings.

Key Features

• 203 dpi resolution at 14 ips for sharp barcode and text output
• 4.09" maximum print width accommodates standard and custom label sizes
• Dual-mode printing: Direct thermal and thermal transfer support maximum media flexibility
• 2 GB Flash and 256 MB SDRAM with 100 MB user storage for forms, fonts, and graphics
• 3.5" full-color LCD display with intuitive touchscreen interface
• Tool-free printhead and platen roller replacement minimizes maintenance downtime
• Multiple connectivity options: Ethernet, Wi-Fi, and USB 2.0
• Supports media rolls up to 10" diameter with ribbons to 1,968 ft
• Media width range: 0.87" to 5.04" on 1" or 3" cores

Technical Specifications

• Resolution: 203 dpi
• Print Speed: 14 inches per second
• Maximum Print Width: 4.09 inches
• Memory: 2 GB Flash, 256 MB SDRAM, 100 MB user storage
• Display: 3.5" full-color LCD
• Connectivity: Ethernet, Wi-Fi, USB 2.0, RS-232C, Parallel, Bluetooth 3.0, NFC
• Media Capacity: 10" maximum roll diameter, 1,968 ft ribbon length
• Media Width: 0.87" to 5.04" on standard cores
• Power: AC 100-240V, 50/60Hz
• Operating Temperature: 5°C to 40°C
• Dimensions: 10.66" W × 17.99" D × 12.63" H
• Weight: 33 lbs

Typical Applications

• High-volume shipping and logistics labeling
• Manufacturing identification and tracking
• Warehouse inventory management and routing
• Compliance and regulatory labeling
• Healthcare and pharmaceutical barcode labeling
• Retail and e-commerce order fulfillment

Karl Wilson

Perspective based on aggregated and affiliated engineering team experience.

The SATO WWCLP1001-NMR represents a mature, field-proven platform for enterprises requiring reliable high-volume label production. The dual thermal printing capability provides operational flexibility—direct thermal for cost-sensitive, short-shelf-life labels and thermal transfer for durability-demanding applications. The 203 dpi resolution strikes a practical balance between output quality and throughput, suitable for standard GS1-128 and Code128 barcodes without excessive file sizes.

The 2 GB flash storage and multi-protocol connectivity (Ethernet, Wi-Fi, USB, Bluetooth, NFC) enable seamless integration into legacy and modern network infrastructures. Tool-free maintenance design reduces operational burden in high-utilization environments. For organizations managing mid-to-large label volumes with consistent specifications, this printer delivers a solid ROI through proven durability and low total cost of ownership.
