Vertiv VP5N30AV Switched Rack PDU

Overview

The Vertiv VP5N30AV is a 30A, 208V switched rack power distribution unit designed for data center and IT closet deployments requiring granular control over individual outlet power. It provides 4.9kW of capacity at 208V, distributed across 36 combination C13/C19 outlets. The unit features bottom front power entry with a NEMA L6-30P twist-lock plug, ensuring secure connection. Its switched functionality allows remote power cycling of connected equipment, which is critical for managing server reboots, troubleshooting, and optimizing power usage in dense IT environments. The VP5N30AV model is specifically designed for vertical rack mounting.

Compatibility

This PDU is compatible with standard 19-inch server racks and cabinets. The NEMA L6-30P plug requires a 30A, 208V circuit. The combination C13/C19 outlets accommodate a wide range of IT equipment power cords, from standard servers and network switches to higher-draw devices. It is suitable for use with most major server brands including Dell, HP, Supermicro, and Cisco, as well as network gear from Juniper, Arista, and others, provided the power and plug requirements are met.

Installation Notes

The unit ships with a 10ft (3m) power cable. Vertical mounting requires sufficient clearance within the rack. The power cable wire gauge is specified as 45726, indicating suitability for the 30A current draw. Ensure the circuit breaker feeding the NEMA L6-30P receptacle is rated appropriately and that the rack's power infrastructure can support the PDU's 4.9kW load capacity at 208V. The PDU itself has 36 LED indicators for status monitoring.
