Vertiv VP7N30AV Switched Outlet Level Monitoring EC 30A 208V Vertical (36) Comb
Overview
The Vertiv VP7N30AV is a 30A, 208V switched rack power distribution unit (PDU) designed for enterprise data centers and network closets. It offers remote outlet control and monitoring capabilities, allowing you to manage power to individual IT devices. This vertical PDU installs directly into standard 19-inch racks, maximizing power density where it's needed most. The VP7N30AV model provides 30 U-Lock C13 outlets and 6 U-Lock C19 outlets, supporting a wide range of server and network equipment.
Compatibility
This PDU is designed for use in standard 19-inch rack enclosures. It operates with a 208V input and output voltage, making it suitable for North American data center power configurations. The U-Lock connectors ensure that standard C14 and C20 power cords remain securely attached, preventing accidental disconnections that could disrupt critical operations. It is compatible with equipment requiring C13 or C19 power connections.
Installation Notes
The VP7N30AV is a vertical PDU, designed to mount directly into the vertical mounting rails of a 19-inch rack. Ensure sufficient clearance within the rack for the PDU's length and the connected power cords. The unit requires a 208V, 30A circuit. It is RoHS, UL & c-UL Listed 60950 and FCC Part 15 Class A compliant, meeting stringent safety and interference standards for deployment in commercial environments.
What's in the Box
- 1x Vertiv VP7N30AV Switched PDU
- 1x Power Cord (attached)
- 1x Mounting Hardware Kit
