Vertiv Rpdu Rack Transfer Swch 30A 208V 4.9KW 1 - VA1N3102

Vertiv VA1N3102 1U Horizontal Basic Rack PDU 30A 208V

Overview

The Vertiv VA1N3102 is a single-phase, 1U horizontal basic PDU rated at 30A / 208V (4.9 kW capacity), designed for high-density rack environments where you need a reliable, no-frills power distribution unit that doesn't consume valuable rack space. With a NEMA L6-30P input plug, 12 total AC outlets split between C13 and C19 form factors, and a 3-meter input cord, the VA1N3102 is a straightforward fit for data center rows, colocation cages, and enterprise server racks running 208V branch circuits. If you're building out a rack with a mix of 1U servers and high-draw storage or networking gear, this PDU covers the outlet mix without forcing you into a metered or switched model you don't need.

Key Features

• 30A / 208V Single-Phase Input (NEMA L6-30P): The L6-30P plug targets standard 208V 30A circuits common in North American data centers — no adapters, no rewiring. At 4.9 kW total load capacity, this PDU can support a fully populated 1U server rack without headroom concerns on a properly rated 30A circuit.
• 12 AC Outlets — Mixed C13 and C19: C13 outlets handle standard 1U/2U servers and networking gear (up to 15A per IEC standard); C19 outlets support higher-draw equipment like high-density blade chassis, large UPS bypass loads, or storage arrays drawing up to 20A per outlet. Having both coupler types on one unit avoids the need for C14-to-C20 adapters scattered across your rack.
• 1U Horizontal 0U-Equivalent Form Factor (432 × 457 × 44 mm): At 44mm tall (true 1U) and 457mm deep, the VA1N3102 mounts horizontally in a standard 19-inch rack without consuming a vertical outlet strip position. The 432mm width fits EIA-310 19-inch rack rails directly.
• 3-Meter Input Cord: The 3m (approximately 10 feet) cord gives you enough reach from the PDU to the overhead busway, floor-mount UPS, or branch circuit panel without resorting to extension cords — a common compliance concern in data center environments.
• Over-Current Protection: Built-in over-current protection trips before a fault on one outlet cascades into a full-rack power loss. For basic PDUs without per-outlet switching, this is the primary defense against a single connected device pulling down the entire unit.
• Wide Operating Temperature Range (0–60°C): Rated to 60°C — comfortably above the ASHRAE A2 inlet temperature ceiling of 35°C and the A3/A4 extended ranges used in some high-density rows. This PDU won't be the thermal weak link in a warm-aisle/cold-aisle containment configuration.
• 200–240V Input Compatibility, 50/60 Hz: The VA1N3102 accepts input across the full 200–240V range at both 50 and 60 Hz, making it deployable in international facilities, colocation sites with mixed voltage infrastructure, or future-proofed for sites transitioning from 208V to 240V distribution.

Integration & Compatibility

As a basic (non-metered, non-switched) PDU, the VA1N3102 requires no network provisioning, no SNMP configuration, and no management software — it's powered on and functional the moment it's installed. This keeps initial deployment fast in high-count rollouts where per-PDU configuration time adds up. It pairs naturally with an external branch circuit monitor at the panel if visibility into per-circuit load is required by your facility management team. The C13/C19 outlet mix is compatible with standard IEC 60320 power cords found on virtually all rack-mount server, storage, and networking equipment from major OEMs. For rack PDUs that require metering or remote outlet switching, consider a stepped-up model in the Vertiv power distribution lineup — the VA1N3102 is the right fit when budget and simplicity are the primary constraints and 24/7 remote monitoring isn't operationally required. If you're planning a full rack build with UPS systems and structured power distribution, review the data center power planning guide for branch circuit sizing and PDU selection criteria.

Frequently Asked Questions

Q: What input plug does the VA1N3102 use, and what circuit does it require?

A: The VA1N3102 uses a NEMA L6-30P input plug, which requires a 30A 208V (single-phase) dedicated branch circuit. This is a locking plug — confirm your panel has a matching NEMA L6-30R receptacle before ordering.

Q: How many C13 vs. C19 outlets does the VA1N3102 have?

A: The VA1N3102 provides 12 total AC outlets in a mix of C13 and C19 couplers. The exact per-type split is not specified in available documentation — verify against the physical product or Vertiv's product detail page if your application requires a specific count of C19 outlets.

Q: Does the VA1N3102 support remote monitoring or outlet-level switching?

A: No. The VA1N3102 is a basic PDU — it provides no metering, no SNMP/network management, and no per-outlet switching. It distributes power passively with over-current protection. If remote monitoring or switching is required, a metered or switched PDU model is the appropriate choice.

Q: What rack mounting orientation does the VA1N3102 support?

A: The VA1N3102 is designed for horizontal rack mounting, occupying 1U (44mm height) in a standard 19-inch EIA-310 rack. It does not support vertical (0U) side-rail mounting.

Q: Is the VA1N3102 compatible with international voltage standards?

A: Yes. The VA1N3102 accepts 200–240V input at 50 or 60 Hz, making it compatible with both North American 208V data center circuits and European/international 230V single-phase infrastructure.

Eden Phillips

The VA1N3102 is one of those PDUs I recommend when a customer's first question is 'how fast can we get this rack live?' — it's a 30A / 208V basic unit with a NEMA L6-30P input, 12 C13/C19 outlets, and zero configuration overhead. No IP address to assign, no firmware to update, no SNMP community string to document. You rack it, plug it in, and distribute power. For greenfield deployments where the monitoring layer is handled upstream at the panel or UPS, that simplicity is a real operational advantage.

Technical Highlights:

• 4.9 kW Load Capacity at 208V: At 30A on a 208V circuit, you're looking at a practical draw ceiling of around 4.8 kW using the standard 80% derate rule — close to the PDU's rated 4.9 kW. Size your connected load accordingly; don't assume you can run all 12 outlets at full draw simultaneously on a heavily loaded circuit.
• Mixed C13/C19 Outlet Array: The combination of C13 and C19 couplers on a single unit eliminates the adapter tax on racks mixing standard 1U servers (C14 inlets) with higher-draw storage controllers and blade modules (C20 inlets). Both IEC 60320 coupler types are covered natively.
• 0–60°C Operating Range: The 60°C upper limit gives this PDU thermal clearance beyond ASHRAE A2 (35°C) and into A3/A4 territory — relevant in high-density rows where inlet temperatures can climb. The PDU won't fail before your servers do in an over-temperature event.

Deployment Considerations:

• The 3-meter cord is sufficient for most raised-floor or overhead busway drops, but measure your panel-to-rack run before ordering — field-extending a PDU input cord with a whip is a compliance gray area in many facilities.
• No per-outlet current monitoring means load balancing across the 12 outlets is manual. In a mixed C13/C19 configuration, it's easy to overload the C19 positions if high-draw devices are concentrated — distribute load intentionally and document per-outlet draw at commissioning.

The VA1N3102 is the right call for edge deployments, secondary colocation cages, or lab racks where 208V power is available, the connected load is well-characterized, and management overhead needs to stay at zero.
