Vertiv Rpdu Rack Transfer Switch Monitored Outlet Level 30A 208V 4.9KW Horizontal - VA6N31A0

Vertiv VA6N31A0 Rack Transfer Switch Monitored Outlet Level 30A 208V 4.9KW Horizontal

Overview

The Vertiv VA6N31A0 is a horizontal rack transfer switch designed for critical IT infrastructure. It provides monitored outlet-level power distribution with a 30A capacity at 208V, supporting up to 4.9kW. This unit is essential for ensuring continuous power to sensitive equipment by allowing seamless switching between redundant power sources, preventing downtime during power events. Its rack-mountable form factor makes it suitable for data centers and server rooms.

Compatibility

This transfer switch is designed for integration into standard 19-inch rack environments. It operates with input voltages between 200-240V and outputs at 208V via a single NEMA L6-30R outlet. It supports standard networking protocols including DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Syslog, and TACACS+ for robust network management and security. It is suitable for deployment with various server and network devices requiring reliable, switched power.

Installation Notes

The VA6N31A0 operates within an ambient temperature range of up to 60°C (140°F). Its physical dimensions are 44 mm in height, designed for horizontal rack mounting. The unit supports both 50Hz and 60Hz frequencies. It is RoHS Compliant, FCC Part 15 Class A compliant, and UL Listed to UL 62368 standard, ensuring adherence to safety and environmental regulations.

What's in the Box

• 1x Vertiv VA6N31A0 Rack Transfer Switch
