Vertiv VP4N60AE Monitored Rack PDU, 0U Vertical, 60A/208V
Overview
The VP4N60AE is a Geist-series 0U vertical monitored rack PDU designed for dense compute and power distribution deployments where per-outlet visibility and fault tolerance are non-negotiable. At 60A/208V Delta and 17.2 kW of usable capacity, it handles fully populated high-density racks without derating concerns. The 30 combination C13/C19 outlets accommodate a mix of 1U servers, GPUs, and storage nodes without adapter chains. The hot-swappable monitoring device means the Vertiv PDU stays powered during firmware or controller replacement — critical in always-on data center environments where any maintenance window carries risk. An LCD touchscreen and color-coded P-Lock tabs reduce mis-plug incidents during provisioning or moves-adds-changes. Input power monitoring at the unit level gives real-time kW draw for per-rack capacity planning without deploying an external meter.
Compatibility
Fits any 42U or taller open-frame or enclosed rack with a 0U vertical tooling channel — standard across rack enclosures from Vertiv VR/VX series, APC NetShelter SX/SL, Chatsworth CPI, and equivalent open-frame cabinets. The 3P+E IP44 input plug connects to 208V delta three-phase PDU circuits common in North American co-location and enterprise data halls. Dual Ethernet ports support daisy-chaining up to 16 units under a single IP address for aggregated monitoring, or can be used for independent IP assignment where isolation is required. The environmental sensor port accepts compatible Vertiv Geist probes (temperature, humidity, airflow) for in-rack environmental data alongside power data in a single management pane. Integrates with network management and DCIM platforms via SNMP, Modbus, and REST API — check Vertiv's compatibility matrix for specific DCIM version support.
Installation Notes
Unit dimensions are 70 × 2.10 × 3 in and weight is 32 lb — plan for two-person lift and confirm vertical channel clearance before ordering for shallow cabinets. Operating temperature rating of 60°C maximum aligns with ASHRAE A2 inlet envelopes; do not install in ambient environments exceeding this threshold. Input cord terminates in a 3P+E IP44 plug — verify the local PDU whip or busway tap matches before deployment. UL Listed and TAA Compliant; suitable for U.S. federal procurement and environments requiring domestically sourced infrastructure.
