Vertiv Rpdu Basic Standard MAX 22.0KW - U1079

Vertiv U1079 Basic Standard, MAX 22.0KW

Overview

The Vertiv U1079 is a 32A basic power distribution unit (PDU) designed for vertical rack mounting in standard data center environments. It provides 48 AC outlets, supporting a maximum load capacity of 22000 VA. This unit is ideal for distributing power to standard IT equipment where advanced monitoring or switching is not required, simplifying power management within a 0U rack space. The U1079 model is finished in black.

Compatibility

This PDU is designed for use with standard 230/400V AC input power systems operating at 50 Hz. It is compatible with any standard 19-inch server rack requiring vertical 0U mounting. Its 48 outlets accommodate a wide range of standard IT equipment power cords.

Installation Notes

The U1079 installs vertically in the 0U space of a standard 19-inch rack. It requires a 230/400V AC input connection with a maximum current draw of 32A. The operating temperature range is 0 to 60 °C, with relative humidity tolerance from 5% to 95% (non-condensing) for both operation and storage. The unit has dimensions of 1683 mm in height, 97 mm in depth, and 57 mm in width.
