Vertiv Rpdu Basic Standard MAX 22.0KW - U1078

Vertiv U1078 Basic Standard, MAX 22.0KW

Overview

The Vertiv U1078 is a basic, vertical rack PDU designed for standard IT deployments where reliable power distribution to multiple devices is required. It provides 24 AC outlets, facilitating the connection of servers, switches, and other rack-mounted equipment within a data center or network closet. The U1078 model is built for straightforward power distribution, fitting into standard 19-inch racks without consuming vertical U space, making it ideal for high-density environments. This unit supports a maximum load capacity of 22000 VA at 32A and operates on a nominal input voltage of 230/400 V with a 50 Hz frequency. Its black color and standard form factor ensure it integrates seamlessly into existing rack infrastructure.

Compatibility

This PDU is compatible with standard 19-inch server racks and enclosures. It is designed for use with IT equipment requiring 230/400V, 50Hz power input and drawing up to 32A. While not specific to a particular brand of rack or server, its universal design ensures broad compatibility across most IT infrastructure components that adhere to standard power and physical dimensions. It is suitable for general-purpose data center and network closet power distribution needs.

Installation Notes

The Vertiv U1078 mounts vertically within a 19-inch rack. It operates within an ambient temperature range of 0 to 60 °C and can handle relative humidity levels from 5% to 95% (non-condensing). The unit is rated for operation at altitudes up to 3050 meters. Its physical dimensions are 1682 mm in height, 51 mm in width, and 64 mm in depth, allowing for efficient integration into standard rack layouts. Ensure the power source can support the 32A maximum current draw.
