Vertiv Rpdu Basic Standard 30A 208V 4.9KW - 11112VH

Vertiv 11112VH Basic Standard, 30A, 208V, 4.9KW

Overview

The Vertiv 11112VH is a basic, horizontal rack PDU designed for straightforward power distribution in standard IT racks. It provides 6 NEMA L6-20R outlets, suitable for distributing 208V power to network devices, servers, and other rack-mounted equipment. Its robust design includes over-current protection, ensuring equipment safety. This unit is ideal for deployments where simple, reliable power is the primary requirement, such as in small server rooms or network closets. The 11112VH model is a single-phase unit with a 30A maximum current rating.

Compatibility

This PDU is compatible with standard 19-inch IT racks and supports horizontal mounting. It is designed for use with 200-240V nominal input voltage and 50/60 Hz AC input frequency. The NEMA L6-30P plug connects to a 30A, 208V circuit. The NEMA L6-20R outlets are rated for 20A block output current, making it suitable for equipment drawing up to that limit per outlet. It is UL & c-UL Listed 60950 certified.

Installation Notes

The PDU features a 3.05-meter (10 ft) power cord, providing ample reach for most standard rack configurations. The operating temperature range is 10°C to 45°C, suitable for typical climate-controlled IT environments. Over-current protection is built into the unit to safeguard connected devices.
