Viking VE-9X12R-OP Red Outdoor Enclosure NEMA 4X UV-Stable

Viking Electronics VE-9X12R-OP Red Heavy-Duty Outdoor Enclosure

Overview

The VE-9X12R-OP is a red, heavy-duty outdoor enclosure from Viking Electronics' VE-9x12 series, built for installations where weather protection and UV stability are non-negotiable. Constructed from UV-stable polycarbonate/ABS composite with a UL 94 V-0 flame retardancy rating, this enclosure is engineered for long-term outdoor deployments — perimeter entry points, exterior utility runs, or any surface-mount installation exposed to direct sunlight, rain, and temperature cycling. The red color aids rapid visual identification in emergency or alarm-signaling installations. At 9.375″ x 12.6″ x 7.45″ (238 mm x 320 mm x 189 mm) and a shipping weight of 6.6 lbs (2.99 kg), the VE-9X12R-OP provides meaningful interior volume for Viking intercom boards, relay modules, or ancillary power hardware without adding excessive bulk to the wall surface. This variant ships without an adapter panel, giving integrators flexibility to fit custom sub-plates or third-party mounting hardware as needed.

Compatibility

Designed for use with Viking Electronics' VE-9x12 series boards and modules. The enclosure's interior dimensions accommodate Viking intercom and entry-system components sized for the 9x12 platform. Mounting holes support direct surface attachment to masonry, metal stud, or wood-framed walls. Because this unit ships without an adapter panel, verify your board mounting requirements before ordering — if a pre-drilled adapter plate is needed for your specific Viking module, the adapter-panel variant of the VE-9x12 series is the appropriate choice. Available in red (this SKU), yellow, and black for installations with specific color-coding or visibility requirements.

Installation Notes

The enclosure carries NEMA/EEMAC Type 4, 4X, and 12 ratings — this covers hose-directed water and dust ingress, making it suitable for covered outdoor locations and wash-down-adjacent environments, though not full submersion. The UL 94 V-0 flame-retardant rating meets fire-safety requirements common in commercial and light-industrial installs. Mounting holes are field-positionable per the VE-9x12 Series Product Manual. Confirm conduit knockout locations match your site wiring approach before final surface attachment.
