Description

Bosch RE92TX Premium Cardioid Lapel Microphone

Overview

The Bosch RE92TX is a cardioid lapel microphone designed for professional audio applications, specifically for use with Bosch wireless microphone systems such as the R100, RE-2, and RE-1 series. Its cardioid polar pattern effectively isolates the primary sound source, minimizing background noise and feedback. This makes it ideal for presenters, performers, or interviewers who require clear, consistent voice pickup in environments with potential ambient sound interference.

Compatibility

This microphone is engineered for direct compatibility with the following Bosch wireless receiver systems: R100, RE-2, and RE-1. It utilizes a standard TA4F connector, ensuring a secure and reliable connection to the bodypack transmitters associated with these systems. Integration with third-party wireless systems is not supported without appropriate adapters, which are not included.

Installation Notes

The RE92TX features a discreet clip-on design for easy attachment to clothing. Its lightweight construction ensures comfort during extended use. For optimal performance, position the microphone approximately 6-8 inches from the mouth, angled slightly towards the speaker. Avoid placing it directly over clothing that may cause rustling or muffled audio. The TA4F connector should be firmly seated into the bodypack transmitter's microphone input.

What's in the Box

  • 1x Bosch RE92TX Cardioid Lapel Microphone
  • 1x Clothing Clip
Specifications
Weight Net: 0.81oz (23g)
Height: 10.5mm (0.41")
Case Material: Metal
Connector Type: TA4F
Current Consumption: < 500 uA
Diameter Max: 24mm (0.94")
Element: Back Electret Condenser
Family: RE Series
Installation Finish: Non-reflecting Black
Maximum Spl: 135dB
Mic Type: Lavalier
Open Circuit Voltage: 5.6mV/Pascal
Polar Pattern: Cardioid
Wired Wireless: Wireless
