Posiflex KT2130P133DFL0 21.5" Pedestal POS Terminal
Overview
The Posiflex KT2130P133DFL0 is a 21.5-inch pedestal-mount point-of-sale terminal designed for retail checkout and hospitality environments requiring integrated payment processing. The unit combines a capacitive touchscreen with an Intel Celeron J1900 processor running Windows 10 IoT, paired with 4GB RAM and 64GB SSD storage — sufficient for single-location transaction management without external storage dependency. Built-in VX820 Verifone EMV support handles certified card-present and contactless transactions directly on the terminal, eliminating the need for a separate external PIN pad in most installations.
Compatibility
This terminal integrates with standard retail POS ecosystems supporting Windows 10 IoT endpoints. The VX820 Verifone EMV module is PCI DSS 3.2 compatible and works with acquiring networks and gateways that recognize Verifone-certified hardware. Verify compatibility with your specific payment processor or VMS before deployment — some systems require firmware updates or gateway configuration changes to recognize the EMV certification chain on this model.
Installation Notes
The pedestal mounting bracket secures to standard 1.5-inch diameter poles or custom stand-offs. Typical footprint is approximately 24 inches deep and 18 inches wide. Mains power (120/240V depending on region) is required — no battery backup is built in. Network connection via Ethernet RJ-45 is standard; no Wi-Fi is integrated. Allow adequate cable routing behind the pedestal to avoid pinching or strain. The capacitive touchscreen requires minimal calibration after power-on but may need re-calibration if relocated frequently.
What's in the Box
- 1x KT2130P133DFL0 pedestal unit with integrated VX820 module
- 1x mounting bracket assembly
- 1x power cable (region-specific)
- 1x RJ-45 Ethernet cable (2 meters)
- 1x quick-start guide
