Viking E-65-PB Polished Brass Video Entry Phone IP67 Flush Mount

Viking Electronics E-65-PB Polished Brass Video Entry Phone with Color Camera

Overview

The Viking Electronics E-65-PB is a telephone-line-powered, flush-mount video entry phone built for commercial and residential access points that demand weather resistance, vandal resistance, and reliable two-way audio without a separate power supply. The polished brass faceplate and stainless steel button give it a professional appearance suited to lobbies, gated entries, and multi-tenant vestibules. It mounts in a standard double gang box or surface-mounts with an optional VE-5x5 enclosure — two paths that cover new construction and retrofit scenarios equally well. For a broader look at the Viking Electronics entry phone lineup, the E-65 series sits in the middle of their outdoor intercom range.

Key Features

• Telephone-Line Powered: The E-65-PB draws power directly from the telephone line, eliminating the need for a local power supply or PoE drop at the door. That simplifies wiring in retrofit installs where running a separate power circuit is costly or disruptive.
• Color Wide-Angle Video Camera: The onboard color camera with composite video output delivers a visual record of who called — useful for both real-time monitoring and post-incident review. Composite output integrates with legacy DVRs and monitors already on-site without requiring an IP infrastructure upgrade.
• Hands-Free Audio: Integrated microphone and speaker with independent volume controls for each handle the full call without requiring the visitor to hold anything. Volume is adjustable on both the mic and speaker sides, so you can tune for noisy loading docks or quiet lobbies.
• IP67 Button / IP66 Rated (EWP Model): The call button is rated IP67 — fully protected against temporary immersion — making it resistant to rain, hose-down cleaning, and standing water at grade-level installations. If you are deploying in a car wash approach lane or a dock wash-down zone, check the specific IP67 button spec before assuming full-body submersion tolerance.
• -30°F to 150°F Operating Range: That thermal window covers unheated parking structures in northern climates and rooftop or south-facing wall installations in desert environments. Most competing entry phones cap at -4°F to 131°F — the extended range matters for outdoor installs in extreme climates.
• Blue LED Indicator: The blue LED gives visitors clear visual confirmation the unit is active and a call is in progress — reduces repeat button presses and the resulting nuisance alerts at the base station.
• CPC / Silence / Busy Signal / Time-Out Call Progress Detection: The E-65-PB monitors call progress using four distinct detection methods. This means the unit auto-disconnects reliably when the called party hangs up, hangs up without answering, or the call times out — no stuck open-line situations that tie up the phone system.
• Gel-Filled Butt Connectors: Connections are made with gel-filled butt connectors that seal the splice against moisture ingress. In outdoor installs, unsealed wire splices are a leading cause of intermittent failures — the gel fill addresses that at the factory level.
• Compact Flush Profile: The faceplate measures 4.875" x 4.938" x 0.17" with the phone body at 2.84" x 1.8" x 1.65". It fits inside a standard double gang box cutout, keeping the door frame modification minimal on retrofit projects.

Integration and Compatibility

The E-65-PB connects to standard POTS telephone lines or analog PBX extensions. The composite video output feeds any monitor or DVR with a composite input. Surface mounting is supported via the VE-5x5 enclosure (sold separately). For video entry phone and intercom system pairings, confirm your base station or DVR accepts composite video input before ordering. This unit does not output IP video — it is not an IP intercom and does not integrate natively with VMS platforms or SIP systems without additional analog-to-SIP gateway hardware. Review your access control infrastructure to verify analog line availability at the door location.

Frequently Asked Questions

Q: Does the E-65-PB require a separate power supply at the door?

A: No. The E-65-PB is telephone-line powered — it draws operating power directly from the connected POTS or analog PBX line, so no local power supply or PoE is needed at the door.

Q: What video output does the E-65-PB use, and what can I connect it to?

A: The camera outputs composite video. It connects to any monitor, DVR, or video distribution device with a composite (RCA or BNC) video input. It does not output IP video.

Q: What is the ingress protection rating on the E-65-PB?

A: The call button is rated IP67, protecting against temporary water immersion. The EWP variant of the E-65 series carries an IP66 rating for the full enclosure. Confirm which variant you have for full-body IP rating details.

Q: Can the E-65-PB be surface mounted without a wall box?

A: Yes. It flush-mounts in a standard double gang electrical box, or it can be surface mounted using the optional VE-5x5 surface mount enclosure, sold separately.

Q: What temperature range does the E-65-PB support?

A: It is rated from -30°F to 150°F, making it suitable for extreme cold in unheated outdoor structures and high-heat environments like south-facing exterior walls in hot climates.

Q: Does the E-65-PB automatically disconnect calls?

A: Yes. It monitors call progress using CPC detection, silence detection, busy signal detection, and time-out. It disconnects automatically when any of those conditions are met, preventing stuck open-line situations.

Ted Perry

The E-65-PB stands out to me primarily because of its -30°F to 150°F operating range — that is an 180-degree thermal window that most analog entry phones simply do not offer, and it directly determines whether this unit survives a Minnesota parking structure winter or a Phoenix rooftop enclosure in July without a heater kit or shade canopy.

Technical Highlights:

• Telephone-Line Power: No power circuit at the door means lower install cost and no NEC box requirement for a separate feed — on retrofit multi-tenant entry points, this alone can cut rough-in labor by an hour or more per door.
• IP67 Button Rating: The button surviving temporary immersion is a meaningful spec at grade-level installs — dock approaches, wash-down corridors, and covered but not enclosed entries where water pooling is routine.
• Four-Mode Auto-Disconnect: CPC plus silence, busy, and time-out detection together mean the unit handles edge cases a single-mode detector misses — specifically, analog PBX lines that do not send CPC on hang-up. That matters when integrating with older on-premise phone systems.

Deployment Considerations:

• Composite video only — if your monitoring station has migrated to IP, budget for a composite-to-IP encoder or a dedicated composite monitor at the base; there is no SIP or IP video path in this unit natively.
• The VE-5x5 surface mount enclosure is sold separately — confirm you have it on the BOM before the install date if you are not cutting a double gang box into the wall.

This unit is the right call for multi-tenant residential lobbies and light-commercial entry points on analog PBX infrastructure where a line-powered, weather-hardened intercom with visual confirmation is required and IP infrastructure at the door is not available or not justified by the project budget.
