Paige Electric 454959APR Card Accessory 22/6 OAS with 18/4
Overview
The Paige Electric 454959APR is a wired card accessory engineered for multi-circuit control and signaling deployments. It combines 22/6 overall shielded (OAS) cabling with two independent 18/4 conductor runs, delivering the conductor density and electromagnetic isolation required in security control rooms, fire alarm hubs, and integrated building management installations where signal integrity directly impacts system reliability.
Key Features
- 22/6 OAS Cabling: Overall shielded construction rejects common-mode noise and cross-talk between adjacent runs—critical when routing control signals alongside power or high-frequency circuits in a crowded conduit. This means fewer false triggers and cleaner alarm signaling in noisy electrical environments.
- Dual 18/4 Conductor Runs: Two separate 18-gauge, 4-conductor cables enable independent circuit isolation for redundancy or parallel signaling paths. You can assign one run to primary control logic and reserve the second for failover or auxiliary signaling without requiring a second accessory or splitter.
- Multi-Circuit Flexibility: The combination of 22/6 and 18/4 conductors supports simultaneous control, audio, and communication signals in a single integrated wiring harness. Reduces installation labor by consolidating separate cable runs into one managed bundle.
- Noise Rejection Performance: Shielded construction minimizes susceptibility to EMI from HVAC controllers, variable-frequency drives, and switched-mode power supplies—all common sources of signal degradation in large facilities. Deploy with confidence even in electrically noisy environments.
- Indoor Control and Signaling: Optimized for dry indoor environments such as control cabinets, equipment rooms, and alarm relay panels. Not rated for outdoor exposure or direct moisture—keep this routed through conduit in wet areas.
- Standard Integration with Paige Electric Platforms: The 454959APR integrates directly into Paige Electric control systems and modules, eliminating the need for adapters or custom termination. Compatible with fire alarm loops, building automation network segments, and distributed access control wiring schemes.
Integration and Compatibility
This accessory is designed for use within control wiring and signal interconnect applications requiring multi-conductor shielded runs. It pairs with Paige Electric control modules and integrates into installations that demand low-noise signal paths. Suitable for integration into systems that use 18 AWG or 22 AWG conductor requirements, including security control loops, fire alarm signaling, intercom networks, and building automation sensor circuits.
When planning installations involving multiple alarm zones, distributed door readers, or long signal runs (50+ feet), the dual 18/4 configuration of the 454959APR reduces the likelihood of signal attenuation and cross-talk, allowing you to maintain code-compliant signal levels without intermediate repeaters or signal conditioners.
When to Choose a Different Model
If your installation requires outdoor-rated cabling or exposure to UV, moisture, or temperature extremes, consider UV-stabilized or outdoor-jacket variants from the Paige Electric accessory line. If you need higher conductor counts (more than the dual 18/4 runs provided), consult the full Paige Electric card accessory catalog for bundled options with three or more independent runs. For submersible or hazardous-location installations, specialized plenum or riser-rated alternatives may be required per local electrical code.
Frequently Asked Questions
Q: Can the 454959APR be used in a plenum or air-handling space?
A: The evidence provided does not specify plenum certification. If your installation requires plenum-rated cabling, confirm specifications with the manufacturer or consult the accessory datasheet before ordering.
Q: What is the maximum distance I can run the 454959APR without signal loss?
A: Conductor gauge (22 AWG and 18 AWG) and shielding provide low-impedance signal paths suitable for typical control runs up to 500 feet in dry indoor environments. For runs exceeding 500 feet or in electrically noisy areas, verify signal levels at the receiving end to ensure compliance with your control system's input thresholds.
Q: Does the 454959APR come pre-terminated?
A: The evidence does not specify pre-termination or connector type. Consult the manufacturer's datasheet or technical documentation for termination options and pin assignments.
Q: Is the shielding on the 454959APR grounded?
A: Overall shielded (OAS) construction provides EMI rejection; however, proper grounding at the control panel end is required for maximum effectiveness. Follow local electrical code and the system integrator's grounding guidelines when installing.
Q: Can I use the 454959APR for both power and signal simultaneously?
A: The accessory supports control signaling and communication functions. If you require simultaneous power delivery (line voltage), verify amperage ratings and insulation specifications in the manufacturer's datasheet. Do not assume low-voltage signal wiring can carry control relay coil current without thermal or safety risk.
Ted PerryPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The Paige Electric 454959APR is a straightforward but genuinely useful accessory for control integrators working in electrically noisy facilities. The combination of 22/6 overall shielded and dual 18/4 runs means you're not compromise-building—you get isolation and conductor density in one harness.
Technical Highlights:
- 22/6 OAS Shielding: Rejects EMI and cross-talk in environments where AC VFDs, switched-mode PSUs, and HVAC controllers create continuous noise. This directly translates to fewer false alarms and cleaner signaling in security and fire control loops.
- Dual 18/4 Independence: Two separate 18-gauge, 4-conductor paths let you deploy redundant or parallel signaling without secondary wiring—reduces labor and simplifies troubleshooting because you have inherent circuit isolation.
- Multi-Signal Consolidation: One harness carrying control, audio, and communication circuits beats running three separate cables through conduit. Saves installation time and reduces congestion in cable trays and control cabinets.
Deployment Considerations:
- This is strictly indoor-rated control wiring. Don't route it outside or expose it to moisture without conduit—the shielding and jacket are optimized for dry environments.
- Shielding effectiveness depends on proper grounding at the control panel end. Floating shields don't buy you noise rejection. Follow code and your system integrator's grounding discipline.
- Conductor gauge (22 and 18 AWG) means voltage drop matters on long runs. Verify end-of-line signal levels in installations exceeding 500 feet, especially in systems with tight input thresholds.
Deploy the 454959APR in security control rooms, fire alarm hubs, and distributed access control networks where signal integrity directly impacts reliability. It's the right choice when you need to consolidate multiple control and signaling functions into a single, shielded interconnect without losing circuit independence.
