Paige Electric 2S22062B5 22/6c Stranded Plenum Cable
The 2S22062B5 is a 500 ft. box of 22 AWG, 6-conductor stranded copper cable rated CMP/FPLP, built for access control and security wiring runs inside plenum air spaces where code requires low-smoke, fire-resistant jacketing. Stranded conductors give it the flex needed for panel terminations and tight pulls through junction boxes, and the 6-conductor count covers reader data, power, and auxiliary contacts in a single run.
Compatibility
Use this cable for wiring access control readers, door strikes, and request-to-exit devices, along with low-voltage alarm and intercom circuits that call for a 6-conductor 22 AWG stranded run. The CMP (plenum) rating qualifies it for installation in ducts, plenums, and other air-handling spaces without conduit, and the FPLP designation confirms it meets fire alarm power-limited circuit requirements — check local and NFPA 70 (NEC) code before running any cable in a return-air plenum without conduit.
Installation Notes
Stranded 22 AWG conductors terminate cleanly at screw terminals or crimp connectors typical of access control panels and door hardware — no solid-core stiffness fighting you at the panel. Rated for indoor environments only, so keep runs inside conditioned or plenum spaces and route outdoor or underground segments with a direct-burial or riser-rated cable instead. Factory-new, US-manufactured stock with a limited warranty from Paige Electric backs the reel.
What's in the Box
- 1x 500 ft. box of 22/6c stranded copper cable (CMP/FPLP)
