Middle Atlantic ORI 15/16 Dynamic Slope 1 Charcoal Gray - AUO22DS1G1CHG

Middle Atlantic AUO22DS1G1CHG ORI Acoustic Ceiling Tile Dynamic Slope 1 Charcoal Gray

Overview

The Middle Atlantic AUO22DS1G1CHG is a 2' x 2' acoustic ceiling tile from the ORI series, designed for integration into commercial AV and security equipment spaces where sound management and clean aesthetics both matter. Finished in Charcoal Gray with a Dynamic Slope 1 profile, this tile installs directly into standard 15/16" layin grid ceilings — the most common suspended ceiling format found in conference rooms, control rooms, and open office environments. It's a purpose-built component of Middle Atlantic's AV infrastructure line, not a commodity drop-in tile, and it's worth understanding what separates it from a standard acoustic ceiling product before specifying.

The AUO22DS1G1CHG is constructed from PET felt (100% polyester), a material class that delivers meaningful acoustic absorption without fiberglass concerns in occupied or sensitive spaces. The Dynamic Slope 1 geometry introduces a shallow angled surface across the tile face — relevant to both the acoustic behavior of the panel and the visual language of the ceiling plane in finished installations. At 2 inches in both height and width profile, this is a low-profile tile that fits flush within standard ceiling grid systems without requiring additional clearance above the grid plane.

Key Features

• 15/16" Layin Mounting: Drop-in installation into the most widely deployed suspended ceiling grid standard means no custom hardware, no modification to the existing ceiling mount infrastructure, and predictable fit in the vast majority of commercial build-outs. Specify with confidence for retrofit jobs where grid replacement is off the table.
• 2' x 2' Tile Format: The 60.33 x 60.33 cm footprint matches the dominant ceiling module used in North American commercial construction. Swapping out an existing 2x2 tile for the AUO22DS1G1CHG requires no grid reconfiguration — one tile out, one tile in.
• PET Felt Construction (100% Polyester): PET felt panels deliver diffuse acoustic absorption across mid and high frequencies, which reduces flutter echo and ambient noise buildup in rooms with hard parallel surfaces — a real factor in control rooms and huddle spaces where mixing bare ceiling tile with reflective equipment racks creates noticeably poor acoustics. 100% polyester composition means no fiberglass particulate, which matters in occupied spaces during installation or service.
• Dynamic Slope 1 Profile: The angled surface geometry of this profile does two things: it scatters reflected sound rather than returning it specularly (reducing comb filtering in critical listening or voice-intelligibility environments), and it provides a distinct visual texture that distinguishes ORI-equipped bays from standard flat-tile areas in the ceiling grid — useful when the ceiling design needs to visually demarcate an AV zone or equipment bay.
• Charcoal Gray Finish: In control rooms and equipment areas where ceiling tiles are visible against dark rack finishes, Charcoal Gray reads as intentional rather than contractor-default white. It also reduces visible soiling over time in high-traffic or dusty environments — a maintenance consideration for facilities teams on long replacement cycles.
• 2-Inch Profile (Height and Width): At 2 in (5.1 cm) both ways, the tile sits within the standard grid without protruding or requiring extra plenum depth above. This matters in tight ceiling assemblies where above-ceiling conduit, cabling, or equipment encroaches on available depth.

Integration and Compatibility

The AUO22DS1G1CHG integrates into any suspended ceiling system using the 15/16" T-bar layin standard — the de facto grid type in commercial construction. It is part of the broader Middle Atlantic ORI acoustic ceiling tile system, which means it is designed to work alongside other ORI series tiles, frames, and mounting components as a coordinated system rather than a standalone tile. When specifying for an AV or security equipment room, confirm the existing grid uses the 15/16" runner width; the less common 9/16" narrow-profile grids require different layin components and are not compatible. For installations combining multiple ORI profiles or colors within the same ceiling plane, Middle Atlantic's system architecture allows mixed configurations, so the AUO22DS1G1CHG can coexist with other ORI tiles in the same grid. Consult your acoustic ceiling tile layout plan to confirm module alignment before ordering quantities — ceiling grid modules and tile counts need to match exactly in layin systems.

Frequently Asked Questions

Q: What ceiling grid type does the AUO22DS1G1CHG require?

A: The AUO22DS1G1CHG uses a 15/16" layin mounting method, which is the most common suspended ceiling grid standard in commercial construction. It is not compatible with 9/16" narrow-profile grid systems.

Q: What are the exact tile dimensions for the AUO22DS1G1CHG?

A: The tile covers a 2' x 2' (60.33 x 60.33 cm) ceiling module. The profile height and width are both 2 inches (5.1 cm).

Q: What material is the AUO22DS1G1CHG made from?

A: It is constructed from PET felt, which is 100% polyester. This material provides acoustic absorption and contains no fiberglass, making it suitable for occupied commercial spaces.

Q: What does the Dynamic Slope 1 profile mean for the tile's performance?

A: The Dynamic Slope 1 designation refers to the angled surface geometry of the tile face. This profile scatters reflected sound rather than returning it at a specular angle, which reduces flutter echo and improves voice intelligibility compared to flat-face tiles in the same grid location.

Q: Is the AUO22DS1G1CHG part of a larger ceiling tile system?

A: Yes. It is part of the Middle Atlantic ORI acoustic ceiling tile series, which includes multiple profiles, colors, and compatible mounting components. Multiple ORI tile variants can be mixed within the same 15/16" layin grid for zoned ceiling designs.

Ted Perry

The AUO22DS1G1CHG is a detail that gets overlooked on rack room and control room builds until the client walks in and wonders why the space sounds like a gymnasium. The 100% polyester PET felt construction and Dynamic Slope 1 profile work together — the material absorbs, the geometry scatters — and in a 2x2 grid bay over a mix of hard rack surfaces and glass, that combination makes a measurable difference in perceived voice clarity. I've spec'd these specifically for NOC-style spaces where operators are on headsets all day and ceiling reflections compound fatigue.

Technical Highlights:

• 15/16" Layin Mount: Drops into the dominant commercial grid without tools or modification — critical on retrofit jobs where you cannot touch the existing grid infrastructure.
• 2' x 2' Format (60.33 x 60.33 cm): One-for-one swap with any standard 2x2 ceiling module; no layout math, no partial cuts needed when replacing an existing tile in a finished ceiling.
• PET Felt (100% Polyester): No fiberglass particulate during install or service — relevant when tiles need to come down for above-ceiling cable work on a live site with staff present.

Deployment Considerations:

• Confirm your grid uses 15/16" runners before ordering. Narrow 9/16" grid systems are common in some Class A office renovations and will not accept this tile's layin edge.
• The Dynamic Slope 1 profile adds a 2-inch raised geometry — verify plenum depth above the grid is sufficient; in tight slab-to-slab assemblies with heavy above-ceiling conduit runs, even 2 inches can conflict with existing infrastructure.

The AUO22DS1G1CHG earns its place in dedicated AV control rooms, NOC environments, and equipment bays where the ceiling is visible, acoustics affect operator performance, and the install crew cannot afford to modify the existing grid during a live-site retrofit.
