Panduit FS2EPKBLBNBM008 OM4+ Duplex LC Fiber Optic Patch Cord 8M Red
Overview
The Panduit FS2EPKBLBNBM008 is an 8-meter (26.25 ft) OM4+ duplex LC fiber optic patch cord from the Panduit Opti-Core line, built for high-density structured cabling environments where polarity control and physical security matter. One end carries a keyed (coded) duplex LC connector; the other is a standard (un-keyed) duplex LC — a deliberate design that locks components together in a coded fiber cabling system, preventing mis-mating and adding a physical layer of security to your patch field. The red zipcord jacket makes this cable instantly identifiable in a busy rack.
Key Features
- OM4+ Signature Core Fiber: OM4+ exceeds standard OM4 bandwidth specs, supporting 40G and 100G applications over longer distances than base OM4 — relevant when you're pre-installing infrastructure that needs headroom for future network upgrades without re-pulling cable.
- Keyed/Un-Keyed LC Ends: The coded connector on one end physically prevents connection to non-coded ports — a practical safeguard in multi-tenant or high-security environments where an accidental cross-connect could mean a network breach or service outage.
- OFNP (Plenum) Flammability Rating: The plenum-rated jacket meets the requirements for installation in air-handling spaces and ceiling plenums without conduit. Specify this in commercial buildings where NEC Article 770 plenum routing applies — using a non-plenum cord in these spaces is a code violation.
- 1.6mm Zipcord Construction: The slim zipcord profile routes cleanly in tight patch panels and high-density enclosures without the bulk of round duplex cable, reducing airflow obstruction in dense switch rooms.
- Ultra-Low Insertion Loss: Panduit's Signature Core manufacturing process targets ultra-low insertion loss at the connectors — less signal degradation per connection means fewer re-tests at commissioning and better margin for end-to-end link budgets in long runs or multi-hop paths.
- RoHS Compliant: Meets RoHS directive requirements — relevant for deployments in EU-regulated facilities or enterprises with environmental compliance mandates on installed equipment.
- Red Jacket — Visual Identification: Red coloring in the Panduit color-coded fiber system allows technicians to identify cable type and polarity assignment at a glance, reducing mis-patch errors during moves, adds, and changes.
- 8-Meter Length: 8M covers most inter-rack and cross-connect runs in a standard MDF or IDF without excess slack, while still providing enough reach for equipment positioned at the back of deep cabinets or adjacent rack positions.
Integration & Compatibility
The FS2EPKBLBNBM008 integrates with Panduit's broader fiber optic cabling systems using the B-coded connector scheme. The coded end mates only with corresponding coded adapter panels or couplers in a Panduit coded system; the un-keyed end connects to any standard LC duplex port. Pair with Panduit OM4+ adapter panels and enclosures for a fully matched end-to-end link. The OFNP rating makes it suitable for both plenum and non-plenum spaces, avoiding the need to stock two jacket types. Carton quantity is 10 units; each package ships as a single cord (Pkg Qty: 1).
Frequently Asked Questions
Q: What does the keyed (coded) LC connector on the FS2EPKBLBNBM008 do?
A: The keyed end physically prevents mating with non-coded LC ports. In a Panduit coded cabling system, this ensures cables only connect to their designated panel ports, adding a layer of physical security and preventing accidental mis-patching.
Q: Is the FS2EPKBLBNBM008 suitable for plenum air-handling spaces?
A: Yes. The OFNP (Optical Fiber Nonconductive Plenum) rating qualifies this cord for installation in plenum air-handling spaces per NEC Article 770 without conduit.
Q: What fiber type is used, and does it support 100G?
A: This cord uses OM4+ multimode fiber. OM4+ exceeds standard OM4 bandwidth, supporting 40G and 100G applications over appropriate distances.
Q: What is the length of the FS2EPKBLBNBM008?
A: The cord is 8 meters (26.25 feet) long.
Q: Does this patch cord meet RoHS requirements?
A: Yes, the FS2EPKBLBNBM008 meets RoHS directive requirements.
The FS2EPKBLBNBM008 is one of those spec-level decisions that looks minor but pays off at commissioning and during MACs (moves, adds, changes). The keyed/un-keyed LC configuration is the detail to focus on: this cord only works as a one-directional link in Panduit's coded panel system, and that's intentional — it prevents technicians (or anyone else) from patching across zones that aren't supposed to be connected.
Technical Highlights:
- OM4+ Fiber Grade: Exceeds standard OM4 modal bandwidth — gives you headroom for 100G short-reach links where OM3 would require careful budget calculations and OM4 leaves less margin than you'd want.
- OFNP Plenum Jacket: Qualifies for open-air plenum routing under NEC 770 — no conduit required, which matters in retrofit projects where pulling conduit through occupied ceilings is impractical or cost-prohibitive.
- 1.6mm Zipcord Profile: Slimmer than standard round duplex fiber, which is a real advantage in high-density patch panels where cable management becomes a routing puzzle.
Deployment Considerations:
- The coded end ONLY mates with Panduit coded LC adapters — confirm your panel ports are coded B before ordering. Mixing coded and standard panels in the same run defeats the polarity-lock benefit and may require adapter couplers.
- At 8 meters, this cord is sized for inter-rack or cross-connect runs. For longer distances (MDF-to-IDF trunk sections), you'll want pre-terminated trunk cables rather than stacking patch cords.
This cord is the right specification for enterprise or healthcare structured cabling installations using Panduit's coded fiber system, particularly where physical-layer security policy requires traceable, tamper-evident port assignments in the patch field.
