Panduit FZ2RLU1ZNNNM002 QuickNet OM4 LC Uniboot Fiber Patch Cable

The Panduit FZ2RLU1ZNNNM002 is a 2-meter OM4 multimode fiber patch cable engineered for high-density data center and enterprise security infrastructure. Featuring LC duplex uniboot connectors and 50/125µm OM4 fiber, this pre-terminated assembly supports 40GBASE-SR4 and 100GBASE-SR4 applications up to 150 meters, making it ideal for IP camera backbone connections, NVR-to-switch links, and cross-connect deployments where rapid installation and cable management efficiency are critical. The LSZH (Low Smoke Zero Halogen) jacket meets stringent fire safety requirements for enclosed spaces including telecommunications rooms, riser pathways, and equipment distribution areas.

Key Features

OM4 Multimode Performance: 50/125µm laser-optimized fiber supports 10G up to 550m, 40G/100G up to 150m—sufficient headroom for surveillance backbone and storage network growth without re-cabling

Uniboot Connector Design: Single-body LC duplex housing reduces patch panel footprint by 50% compared to traditional dual-boot designs, critical for high-density switch deployments in cramped equipment racks

LSZH Fire Safety Compliance: Low Smoke Zero Halogen jacket produces minimal toxic fumes and smoke during combustion, required for plenum-adjacent installations and mandated by many municipal codes for occupied buildings

Pre-Terminated Factory Assembly: Connectors factory-polished and tested eliminate field termination labor, connector waste, and the test equipment overhead—critical for integrators billing fixed-price projects

2-Meter Optimized Length: 6.6-foot reach handles typical rack-to-rack and intra-rack connections without excess slack that complicates airflow management in hot aisle/cold aisle data center layouts

TIA-568.3-D & ISO/IEC 11801 Certified: Meets insertion loss ≤0.35dB and return loss ≥-20dB performance thresholds required for warranty compliance on structured cabling installations

Technical Design & Installation Context: The uniboot LC connector consolidates both transmit and receive fibers into a single push-pull boot, a design advantage when populating 96-port fiber panels where traditional duplex LC cables create cable management chaos. The reduced connector width allows 50% higher port density in the same 1U panel space, directly translating to lower cost-per-port on large surveillance or data center builds. OM4 fiber's 850nm laser optimization delivers effective modal bandwidth of 4700 MHz·km, a 2.3× improvement over OM3 that ensures 40G/100G links maintain bit error rates below 10⁻¹² even in electrically noisy equipment rooms with adjacent PoE++ switches and UPS systems. The LSZH jacket uses halogen-free flame retardant compounds—when burned, it produces <0.5% HCl by mass versus 25-30% for standard PVC, a critical safety margin for egress pathways and occupied telecom closets where smoke toxicity is a life-safety concern. Factory termination uses physical contact (PC) polish to <50nm surface finish, which minimizes back-reflection and ensures the <0.35dB insertion loss needed for multi-span links—hand-polishing in the field rarely achieves this consistency without $15K+ inspection microscopes.

Deployment Advantages for Security & Enterprise Infrastructure: For integrators running fiber backbones between PoE switches and IP camera distribution nodes, the 2-meter length bridges typical top-of-rack to mid-rack distances without the 15-foot+ coils that plague pre-made cable kits from big-box suppliers. Shorter cables reduce latency by 10ns per meter (negligible for video but measurable in storage iSCSI fabrics sharing the same infrastructure), improve airflow by eliminating cable dams in vertical cable managers, and cut material cost—on a 500-camera project with 40 fiber backbone links, specifying correct-length cables saves $800-1200 in cable cost and 6-8 hours of service loop dressing labor. The QuickNet brand indicates Panduit's rapid-deployment product line, which pairs with their cassette-based fiber systems: pull pre-terminated 12-fiber trunks to equipment rooms, break out to uniboot patch cables at the panel, and you've eliminated 95% of field termination labor. When combined with Panduit's FiberRunner cable routing (not included), the 2mm cable diameter and flexible bend radius allow 25mm radius turns without exceeding the 10× diameter minimum bend spec, a practical advantage in congested pathway fills where 3mm round cables kink and attenuate.

This assembly is TIA-568.3-D and ISO/IEC 11801 certified, ensuring it meets the <0.35dB insertion loss and >-20dB return loss performance required for 10-year extended warranties on Category OM4 permanent link certifications. ANSI/TIA-942-B compliance confirms suitability for Rated-3 and Rated-4 data center tiers where redundant backbone paths and <99.982% uptime SLAs demand tested, specification-grade components. For commercial security integrators building IP video infrastructure, specifying pre-terminated OM4 uniboot assemblies reduces on-site labor, eliminates the $8K-12K fusion splicer capital expense, and produces Fluke-certifiable links that satisfy engineer-stamped low-voltage drawings and AHJ final inspections without change orders or re-work.
