Panduit FX2ELQ1SNSNM029 OM3 LC/SC Duplex Fiber 29m Cable

Panduit FX2ELQ1SNSNM029 QuickNet OM3 LC/SC Duplex Fiber Trunk Cable

Panduit FX2ELQ1SNSNM029 is a 29-meter (95.1 ft) factory-terminated OM3 multimode fiber trunk cable engineered for high-speed 10/40/100 Gigabit Ethernet deployments in data centers, telecommunications rooms, and enterprise network infrastructures. This 2-fiber duplex assembly features LC push-pull connectors on one end and SC duplex connectors on the other, delivering field-proven connectivity between active equipment and fiber distribution panels. The 1.6mm low-profile cable diameter enables high-density cable management in congested pathways, while the LSZH (Low Smoke Zero Halogen) jacket meets stringent fire safety codes for enclosed spaces and air-handling plenums. Factory termination eliminates field splicing errors, reduces deployment time by up to 80% compared to on-site termination, and guarantees insertion loss performance backed by Panduit's system warranty.

Key Features

• OM3 50/125µm Multimode Fiber: Supports 10GBASE-SR up to 300 meters and 40/100GBASE-SR4 applications up to 100 meters per TIA-568.3-D, delivering bandwidth headroom for current and future network upgrades without infrastructure replacement.
• LC Duplex to SC Duplex Configuration: Hybrid connector design bridges equipment with different interface standards—LC push-pull connectors provide tool-free insertion/removal at switch/server ports, while SC connectors interface with legacy fiber panels and backbone infrastructure.
• 1.6mm Tight-Buffered Cable: Ultra-slim cable diameter reduces pathway fill by 40% compared to standard 2.0mm constructions, enabling compliant installation in crowded cable trays, overhead ladder racks, and raised-floor environments where space is constrained.
• LSZH Jacket Compound: Halogen-free jacket material emits minimal smoke and toxic fumes during combustion, meeting IEC 60332-1 flame test requirements and NEC Article 770 OFNP (plenum) equivalency for installations in air-circulation spaces and occupied areas.
• Factory Pre-Terminated QuickNet System: Each cable is terminated, tested, and serialized at Panduit's ISO 9001-certified facility, guaranteeing <0.3dB insertion loss per mated pair and eliminating the 12–15% field termination failure rate associated with manual connector installation.
• TIA-942-B Data Center Tier Compliance: Meets structured cabling requirements for Tier II, III, and IV data centers, including main distribution area (MDA) to intermediate distribution area (IDA) trunking and equipment distribution area (EDA) interconnects.
• Pull-Tested Construction: Aramid yarn strength members and strain-relief boots rated for 100N maximum installation load prevent fiber damage during pulls through conduit, cable tray, and J-hooks in horizontal and vertical pathways.
• Aqua OM3 Color Coding: Industry-standard aqua jacket and connector boots provide instant visual identification of OM3 fiber type during maintenance, reducing cross-connection errors in mixed-mode fiber plants containing OM1/OM2/OM4/OS2 infrastructure.

The LC duplex interface uses Panduit's push-pull boot design, which requires 60% less insertion force than standard LC connectors and enables one-handed operation in dense 1U switch environments where finger access is restricted. The physical-contact (PC) polish on both LC and SC ferrules delivers <0.3dB typical insertion loss and >40dB return loss, ensuring low-BER (bit error rate) performance on 10GBASE-SR and 40GBASE-SR4 links operating near the 300m OM3 distance limit. Each connector is factory-inspected via automated interferometry to verify end-face geometry compliance with IEC 61300-3-35 radius-of-curvature, apex offset, and fiber height specifications—eliminating the dirty-connector failures that account for 80% of fiber optic network downtime.

This 29-meter length is optimized for cross-connect applications in mid-sized data centers and campus telecom rooms, spanning typical equipment-row-to-fiber-panel distances while minimizing excess cable slack that complicates cable management and violates minimum bend-radius requirements. The 1.6mm cable diameter allows installation in 1-inch innerduct and 19mm pathway slots without exceeding NEC Chapter 3 fill ratios, and the LSZH jacket's low-smoke-density rating (ASTM E662 <0.5 flame mode, <0.15 flaming mode) satisfies European EN 50575 CPR (Construction Products Regulation) Class Cca requirements for commercial building installations. The cable's operating temperature range of -20°C to +70°C supports both climate-controlled data centers and entrance facility environments subject to seasonal temperature swings.

Panduit QuickNet pre-terminated systems are tested to 5,000 mating cycles per connector (10× typical field usage) and carry a 25-year system warranty when installed per TIA-568 workmanship standards. This factory-serialized cable ships with a printed test report documenting insertion loss and return loss for each fiber pair, providing day-one documentation for ANSI/TIA-942-B data center commissioning audits and ISO/IEC 11801 acceptance testing requirements. The LC/SC hybrid configuration is widely deployed in backbone-to-active-equipment transitions where Cisco/Arista/Juniper switches (LC SFP+ ports) connect to SC-terminated fiber distribution panels, eliminating the need for adapter panels and reducing insertion-loss budgets by 0.5dB per link. For integrators managing phased 10GbE-to-40GbE migrations, this OM3 cable provides the 300m 10GBASE-SR reach required today while maintaining forward compatibility with 100m 40GBASE-SR4 parallel optics and 150m BiDi 40G applications planned for future capacity upgrades.
