Panduit OM3 12F TRUNK OFNP MPO F/LC DUP - FXTYP5EL2SAF170

Panduit FXTYP5EL2SAF170 Concise Descriptor

Overview

The Panduit FXTYP5EL2SAF170 is a 12-fiber, OM3 multimode fiber optic trunk cable assembly designed for high-density data center and enterprise backbone applications. It features MPO connectors on one end and LC duplex connectors on the other, facilitating efficient transitions between MPO-based equipment and LC-terminated patch panels or devices. The OFNP (Optical Fiber Nonconductive Riser) rating makes it suitable for installation in plenum spaces where fire-resistance and low-smoke characteristics are mandated.

Compatibility

This trunk cable is engineered for use with MPO-equipped network switches, transceivers, and patch panels, as well as LC duplex patch panels, network interface devices, and active equipment. It is compatible with standard OM3 fiber optic infrastructure and supports 10 Gigabit Ethernet (10GbE) up to 300 meters and 40/100 Gigabit Ethernet (40/100GbE) up to 100 meters, making it suitable for high-speed data transmission in modern network architectures.

Installation Notes

When installing the FXTYP5EL2SAF170, maintain a minimum bend radius of 1 inch (25mm) for the OFNP rated cable to prevent signal degradation or damage. Ensure MPO connectors are clean before mating to avoid performance issues. The LC duplex connectors are keyed for correct polarity insertion into patch panels or equipment ports.

What's in the Box

• 1x Panduit FXTYP5EL2SAF170 OM3 12F TRUNK OFNP MPO F/LC DUP Cable
