Middle Atlantic NM Outside Elbow PN05 FOG - PN05F18FW

Middle Atlantic PN05F18FW Eclipse PN05 Outside Elbow Fitting — Fog White

Overview

The PN05F18FW is an outside elbow fitting for the Middle Atlantic Eclipse PN05 cable management system, finished in fog white to blend with light-colored ceiling and wall installations. Use this piece wherever a Middle Atlantic cable tray run needs to turn an outside corner — keeping conductors routed cleanly without sharp bends that stress jacket insulation or compromise pull tension on structured cabling. The fog white color matches standard ceiling tile environments common in commercial offices, school buildings, and healthcare facilities where exposed cable tray is visible from below.

Compatibility

The PN05F18FW is purpose-built for the Middle Atlantic Eclipse PN05 series cable tray and raceway system. It mates directly with PN05-series straight sections, couplers, and fittings that share the same profile width and mounting geometry. Do not mix with PN04 or PN06 series components — the cross-section dimensions differ and fittings will not seat correctly. Verify the installed tray series before ordering; the PN05 designation must match across all connected fittings in the run. For cable tray accessories from the same system, pair with PN05 inside elbows, tees, and end caps to complete direction changes and terminations throughout the pathway.

Installation Notes

Position the outside elbow at the corner transition point in the tray run, aligning the fitting flanges flush with adjoining straight sections before securing. This fitting is designed for surface-mounted tray applications — confirm wall or ceiling substrate can support the combined weight of the tray, fitting, and loaded cable bundle. The fog white finish is factory-applied; field painting is not recommended as it may interfere with fitting tolerances or coupling engagement with adjacent raceway components.
