Middle Atlantic NM Outside Elbow PN05 WHI - PN05F18WH

Middle Atlantic PN05F18WH Eclipse PN05 Non-Metallic Outside Elbow Fitting

Overview

The Middle Atlantic PN05F18WH is a white outside elbow fitting for the Eclipse PN05 non-metallic raceway system. When your cable run reaches an exterior corner — a wall-to-wall transition on the outside of a bend — this fitting maintains the raceway's continuous, finished profile rather than leaving an open gap or forcing a field-cut workaround. The PN05F18WH keeps the run protected and visually clean at outside corners in commercial installations where surface-mounted raceway is the practical choice. TAA compliant, making it eligible for federal procurement and GSE contracts where country-of-origin requirements apply.

Compatibility

Designed exclusively for the Middle Atlantic Eclipse PN05 non-metallic raceway series. The PN05 designation is the critical match — this elbow is sized and profiled specifically for PN05-series raceway channels and cover combinations. It is not cross-compatible with PN10, PN20, or other raceway sizes in the Eclipse family. Verify your installed raceway carries the PN05 part number before ordering; mismatched fittings will not seat correctly or close flush.

Installation Notes

Outside elbows are directional fittings — confirm the corner geometry (outside vs. inside) before ordering. The PN05F18WH handles outside corners only; a separate inside elbow fitting is required for interior corners on the same run. White finish matches standard PN05 white raceway components; if your installation uses ivory or other Eclipse color variants, confirm color consistency with the broader PN05 fitting family before mixing.
