Middle Atlantic Nivo 15/16 7 Drop Charcoal Gray - AUNV227DG1CHG

Middle Atlantic AUNV227DG1CHG Nivo Acoustic Ceiling Tile, 7-Inch Drop, Charcoal Gray

Overview

The Middle Atlantic AUNV227DG1CHG is a 2' x 2' acoustic ceiling tile engineered for AV and technology integration environments where sound control and clean aesthetics need to coexist with infrastructure access. Part of the Nivo acoustic ceiling tile system, this tile installs into standard 15/16" lay-in ceiling grids — the ubiquitous T-bar system found in virtually every commercial office, conference room, and operations center — and drops 7 inches below the grid plane to conceal cabling, mounts, and speaker or display hardware while contributing meaningful acoustic performance overhead.

The AUNV227DG1CHG is built from PET felt (100% polyester), a material chosen specifically because it absorbs mid- and high-frequency sound energy rather than reflecting it back into the room. In a conference room or security operations center where multiple people speak simultaneously, that difference matters: hard ceiling tiles amplify reverberation, which degrades speech intelligibility on video calls and in-person discussions alike. The charcoal gray finish integrates with most commercial interior palettes without drawing attention to itself — which is the right behavior for a ceiling tile in a technology-forward installation.

Integrators deploying Middle Atlantic AV infrastructure products will recognize this tile as the acoustic complement to ceiling-mounted speaker, display, or camera systems. It belongs in the same specification conversation as the mounts and enclosures below the ceiling plane.

Key Features

• 15/16" Lay-In Mounting: Drops directly into the standard commercial T-bar ceiling grid without modification. If your facility uses the near-universal 15/16" exposed tee system, this tile installs without special tooling or adapters — a practical advantage when you're retrofitting dozens of tiles across a floor plate.
• 7-Inch Drop Profile: The 7" drop below the ceiling grid creates a defined cavity that accommodates cable management, mounts, or low-profile hardware without requiring a full plenum build-out. If your runs are tight and the drop depth matters, confirm clearance against your specific hardware before specifying.
• 2' x 2' Format: Matches the standard 24" x 24" (60.33 x 60.33 cm) commercial ceiling module. No field cutting required in a standard grid — reduces installation time and waste on larger deployments covering many bays.
• PET Felt Construction (100% Polyester): PET felt is a purpose-built acoustic material. The fibrous polyester matrix dissipates sound energy rather than bouncing it, which reduces room reverberation and improves speech clarity. In a room where video conferencing, intercom systems, or public address speakers are operating, this directly affects the quality of audio capture and reproduction — not just comfort.
• Charcoal Gray Finish: A neutral dark gray that reads as intentional rather than institutional. Appropriate for executive conference rooms, modern operations centers, and broadcast or recording-adjacent environments where a black or dark ceiling treatment is part of the design intent.
• Compact Border Profile (2" H x 2" W): The tile border measures just 2" in both height and width, keeping the visible frame minimal and maintaining sightlines in rooms where ceiling aesthetics are part of the overall integration specification.

Integration and Compatibility

The AUNV227DG1CHG is designed for 15/16" exposed-tee lay-in ceiling systems — the dominant commercial grid standard in North America. It is not designed for 9/16" narrow-tee or concealed spline systems. Verify your existing grid specification before ordering, particularly in older facilities or international projects where grid standards vary.

This tile functions as part of Middle Atlantic's broader acoustic ceiling tile systems for AV integration. It is appropriate for conference rooms, training spaces, security operations centers, and any environment where acoustic treatment is part of the technology design — particularly where ceiling-mounted AV or surveillance hardware is being installed concurrently. Pair it with compatible ceiling mount hardware when the installation includes projectors, displays, or camera systems in the same grid.

Because the tile material is 100% PET felt polyester, it is not intended for wet or high-humidity environments. Indoor, climate-controlled spaces are the correct application.

Frequently Asked Questions

Q: What ceiling grid type does the AUNV227DG1CHG require?

A: The AUNV227DG1CHG is designed for standard 15/16" lay-in (exposed T-bar) ceiling grids. It is not compatible with 9/16" narrow-tee or concealed spline ceiling systems.

Q: What are the exact tile dimensions for the AUNV227DG1CHG?

A: The tile covers a 2' x 2' (60.33 x 60.33 cm) ceiling module. The border profile is 2 inches in both height and width. The drop below the ceiling grid plane is 7 inches (17.8 cm).

Q: What is the AUNV227DG1CHG made of?

A: It is constructed from PET felt — 100% polyester. This material is selected for its acoustic absorption properties, particularly for mid- and high-frequency sound energy common in speech and AV system output.

Q: Is the AUNV227DG1CHG suitable for outdoor or high-humidity installations?

A: No. The PET felt construction is intended for indoor, climate-controlled environments only. It is not rated for outdoor, wet, or high-humidity use.

Q: What does the 7-inch drop mean for cable management and hardware clearance?

A: The 7-inch (17.8 cm) drop creates a cavity between the grid plane and the bottom face of the tile. This space is used to route cables or conceal low-profile mounting hardware without a full plenum build-out, but actual hardware clearance depends on the specific equipment being installed — verify dimensions before specifying for tight applications.

Q: Can the AUNV227DG1CHG be used in rooms with ceiling-mounted AV or surveillance equipment?

A: Yes — this is a primary use case. The tile is part of Middle Atlantic's Nivo system designed for AV integration environments. It is commonly specified alongside ceiling-mounted displays, projectors, speakers, and cameras where acoustic treatment and cable concealment are both required.

Ted Perry

The AUNV227DG1CHG is the spec I reach for when a project combines ceiling-mounted AV hardware with a hard requirement for speech intelligibility — conference rooms with video walls, SOCs with overhead IP speakers, training rooms running 8-hour sessions. The 7-inch drop gives you real working space behind the tile face for cabling and mounts, and the PET felt construction actually does something acoustically rather than just looking like it does.

Technical Highlights:

• 7-Inch Drop (17.8 cm): Enough cavity depth to handle most low-voltage cable bundles and slim mounting hardware without punching through to the plenum — keeps the installation clean and inspection-friendly.
• 2' x 2' Standard Format: Aligns to the 60.33 x 60.33 cm commercial grid module exactly, so there is no field cutting labor on a standard grid. On a 20-tile conference room ceiling, that adds up.
• 100% PET Felt: Unlike mineral fiber or fiberglass tiles, PET felt handles repeated removal and reinstallation for above-ceiling access without crumbling or leaving particulate in the room — relevant when you're pulling cable in phases or adding hardware post-occupancy.

Deployment Considerations:

• Confirm your grid tee width before ordering: the AUNV227DG1CHG is engineered for 15/16" exposed tee only. A 9/16" narrow-tee or concealed system will not accept this tile without grid modification.
• The PET felt material has no moisture rating — do not specify this tile in any space with humidity excursions, condensation risk, or HVAC discharge directly overhead. Climate-controlled, finished interior spaces only.

Best fit: conference rooms and operations centers in the 400–2,000 sq ft range where ceiling-mounted surveillance, AV, or intercom hardware is being integrated alongside an acoustic treatment requirement and the existing grid is standard 15/16" lay-in.
