APC by Schneider Electric Netshelter VX Side Panel 47U Black - AR8367BLK

APC by Schneider Electric AR8367BLK NetShelter VX 47U Side Panel

Overview

The APC by Schneider Electric AR8367BLK is a replacement and add-on side panel engineered specifically for the NetShelter VX 47U open-frame and enclosed rack enclosure family. At 2142 mm tall and 981 mm wide — matching the full external footprint of a 47U NetShelter VX cabinet — this panel installs flush against the rack frame to close off lateral access, control airflow paths, and give a finished, professional appearance in data centers, server rooms, and network equipment closets. If you are building out a NetShelter VX rack from an open configuration or replacing a damaged panel, the AR8367BLK ships in matte black to match APC's standard rack finish.

Side panels on enclosed racks are not cosmetic afterthoughts. They are an active part of hot-aisle/cold-aisle containment: an open side on a rack breaks the pressure differential that keeps cool supply air moving through equipment bays and away from exhaust. Adding or replacing the AR8367BLK restores that containment boundary without any modification to the rack frame itself.

Key Features

• 47U height match (2142 mm / 84.3 in): Designed to the exact height of the NetShelter VX 47U cabinet, so the panel covers the full rack side from floor-level base to top cap — no gaps at the top or bottom that would let bypass air escape the containment envelope.
• 981 mm panel width: Corresponds to the external side dimension of the NetShelter VX depth-range cabinets. Confirm your specific NetShelter VX model's external width before ordering — APC offers side panels in multiple width configurations across the VX range.
• Shallow 32 mm profile: The panel itself is only 32 mm deep, so it adds minimal footprint when the rack is positioned close to a wall or in a tight row. This matters in high-density deployments where centimeters between rows count for cable management and airflow plenum depth.
• Matte black finish: Matches the standard APC NetShelter VX aesthetic. Useful when replacing a single damaged panel without repainting or mismatching cabinet color in customer-facing or colocation environments where visual consistency is audited.
• Airflow containment contribution: Closing the rack side with the AR8367BLK prevents recirculation of hot exhaust air back into equipment intakes — a common cause of thermal events in partially-configured racks. Even a single open side panel can undermine row-level containment efficiency.
• Drop-in NetShelter VX compatibility: APC designs side panels to attach using the existing mounting points on the VX frame — no drilling, no additional hardware beyond what the cabinet already provides. Replacement takes minutes, not a maintenance window.

Integration and Compatibility

The AR8367BLK is designed exclusively for the APC by Schneider Electric NetShelter VX rack enclosure family in the 47U height class. It is not a universal-fit panel and will not correctly align on NetShelter SX, NetShelter CX, or third-party rack frames. Before purchasing, verify your cabinet's rack unit count (47U), external width (981 mm side), and that the frame uses APC's standard VX panel-attachment system.

For rack builds supporting IP surveillance infrastructure — including network video recorders, PoE switches, and storage arrays — proper enclosure integrity directly affects equipment operating temperature and therefore MTBF. Pairing this panel with APC's blanking panels (for unused U-spaces) and a compatible UPS and power distribution solution from the same NetShelter VX ecosystem gives you a fully integrated rack environment built from matched components.

Integrators deploying high-density IP security systems in network switching and NVR rack configurations should also account for cable management: the AR8367BLK side panel closes off lateral cable routing, so plan your horizontal and vertical cable managers before seating the panel. Refer to APC's rack enclosure accessory line for compatible cable management options within the NetShelter VX family.

Frequently Asked Questions

Q: Is the AR8367BLK compatible with all NetShelter VX racks, or only specific depths?

A: The AR8367BLK is sized for the NetShelter VX 47U cabinet at 981 mm panel width and 2142 mm height. Compatibility depends on your specific NetShelter VX model's external side dimensions — APC produces side panels in multiple widths for different cabinet depths. Verify the external width of your cabinet matches 981 mm before ordering.

Q: Can the AR8367BLK be used on non-APC rack enclosures?

A: No. This panel is designed for APC NetShelter VX frame attachment points. It will not correctly fit or secure on third-party rack frames or other APC rack families (SX, CX, etc.).

Q: Does this panel improve cooling performance?

A: Yes, indirectly. Closing an open rack side with the AR8367BLK eliminates a bypass path where hot exhaust air can recirculate back to equipment intakes. This restores the hot-aisle/cold-aisle pressure differential and reduces the risk of thermal events in densely loaded racks.

Q: What does the AR8367BLK weigh, and is special handling required for installation?

A: The packaged weight is 20.4 kg (approximately 45 lbs). At 2142 mm tall, two-person handling is recommended during installation to avoid panel flex and to align the mounting points accurately on the VX frame.

Q: Does the AR8367BLK include mounting hardware?

A: Package contents are not detailed in available evidence. Contact your supplier to confirm whether mounting hardware is included or must be sourced separately from the NetShelter VX accessory kit.
