APC by Schneider Electric Netshelter SX 48U 600MM Wide Perforated Curved Door Black - AR7007

APC by Schneider Electric AR7007 NetShelter SX 48U 600mm Wide Perforated Curved Door

Overview

The AR7007 is a factory-replacement perforated curved front door designed for APC NetShelter SX 48U, 600mm-wide rack enclosures. If your existing door has been damaged, lost its seating hardware, or you're completing a partially-kitted enclosure build, this is the direct OEM-matched replacement — not an aftermarket approximation. The 600mm width designation is critical: NetShelter SX enclosures ship in 600mm and 750mm wide variants, and doors are not interchangeable between them. Confirm your enclosure's width before ordering.

The curved perforated design is standard across the APC NetShelter SX line and serves a functional purpose: the perforation pattern supports front-to-rear rack enclosure airflow without restricting convective cooling, while the curved profile adds structural rigidity across the 2182mm door height. Black finish matches standard NetShelter SX chassis color.

Key Features

• 48U height compatibility (2182mm door height): fits the full 48U NetShelter SX chassis — that's enough vertical space to house an entire mid-size IDF or server room stack in a single enclosure. Replacing a door on a partially-loaded 48U rack without pulling equipment is straightforward since this door mounts and removes independently of the enclosure frame.
• 600mm width specification: the door panel itself measures 600mm wide, matching the narrow NetShelter SX footprint. This matters in constrained data closets and telecom rooms where every millimeter of aisle width counts — a 750mm door will not fit and should not be forced.
• Perforated curved panel construction: perforation allows airflow through the door face rather than around it, supporting front-intake equipment like 1U/2U servers and network switches that rely on positive front-to-rear airflow paths. The curve adds torsional stiffness to a door spanning over two meters.
• Factory-matched finish and hardware: OEM-sourced replacement means hinge points, latch positions, and swing clearance match the original enclosure specification. Aftermarket doors frequently require modification to the frame or use non-standard hardware that compromises door alignment over time.
• Compact shipping profile: the package ships at 679mm x 2248mm x 121mm and 19kg — manageable for a two-person install team without lifting equipment, though the 2248mm package length requires freight-class shipping in most cases. Plan your receiving dock accordingly.

Integration and Compatibility

The AR7007 is designed for APC NetShelter SX 48U enclosures with 600mm width. NetShelter SX enclosures are widely deployed alongside APC UPS systems, PDUs, and blanking panel kits in structured IT environments. Before ordering, verify your enclosure model number against APC's NetShelter SX compatibility documentation — the 48U, 600mm-wide chassis is the correct host for this door. Do not attempt to fit this door to NetShelter VX, SV, or CX enclosures, which use different frame geometries and hinge standards.

Frequently Asked Questions

Q: Which APC enclosures is the AR7007 compatible with?

A: The AR7007 is designed for APC NetShelter SX 48U enclosures with a 600mm wide frame. It is not confirmed compatible with other NetShelter series (VX, SV, CX) or 750mm wide SX variants. Verify your enclosure model before ordering.

Q: What are the physical dimensions of the AR7007?

A: The door panel measures 600mm wide x 35mm deep x 2182mm tall. The shipping package measures 679mm x 2248mm x 121mm and weighs 19kg.

Q: Is the AR7007 the front door or the rear door?

A: The AR7007 is listed as a front perforated curved door for the NetShelter SX 48U. Confirm with APC's enclosure accessories selector if you need the rear door variant, as APC uses separate model numbers for front and rear doors.

Q: Does the AR7007 include mounting hardware?

A: Package contents are not confirmed in the available evidence. Contact the seller prior to ordering if hardware inclusion is critical to your installation plan.

Q: Can the AR7007 be used with non-APC racks?

A: No. The AR7007 is an OEM-matched door for APC NetShelter SX enclosures specifically. Hinge geometry and latch positions are proprietary to the NetShelter SX frame and will not align with third-party enclosures.

Eden Phillips

The AR7007 is a part most integrators only think about when something goes wrong — a door hinge fails on a live rack, a perforated panel gets cracked during a site buildout, or an enclosure ships incomplete from a secondary reseller. The 2182mm door height is the most unforgiving spec here: at that length, a warped or misaligned door creates sustained airflow bypass that can push hot-aisle temps up measurably over weeks, not hours.

Technical Highlights:

• 600mm width lock-in: the 600mm panel is not adjustable. NetShelter SX enclosures in 750mm wide configurations require a separate door SKU — ordering the wrong width is a common mistake on mixed-width deployments.
• 2182mm door height: spans the full 48U chassis. A door of this height requires two people to hang safely — one to support the weight (19kg shipping, door itself lighter) and one to seat the hinges.
• Perforated panel airflow: perforation is sized for NetShelter SX airflow modeling. Substituting a solid door on a front-intake rack load will restrict airflow and void thermal design assumptions for the enclosure.

Deployment Considerations:

• The 2248mm package length almost certainly requires LTL freight, not small-parcel shipping — confirm carrier options before purchase if your site has dock constraints.
• This door is OEM-matched to NetShelter SX geometry. Any enclosure identified as NetShelter VX, SV, or CX uses different frame and hinge standards; the AR7007 will not fit those chassis without modification.

Best fit for facilities teams managing a standardized NetShelter SX 600mm footprint across multiple IDF closets or a central MDF — where maintaining door uniformity, airflow consistency, and genuine OEM fit matters more than sourcing a cheaper aftermarket panel that may never seat correctly.
