APC by Schneider Electric Netshelter SX 45U 600MM Wide Perforated Curved Door Black - AR7005

APC by Schneider Electric AR7005 NetShelter SX 45U 600mm Perforated Curved Front Door

Overview

The AR7005 is a replacement perforated curved front door designed specifically for APC NetShelter SX 45U enclosures with a 600mm-wide frame. If your existing door has been damaged, lost a hinge, or you are retrofitting an open-frame rack into a proper enclosure, this is the direct OEM-matched replacement — no modification required for compatible NetShelter SX 600mm chassis. The door ships in black and weighs 24.93 lb (11.31 kg), so a second person during installation is practical rather than optional.

At 80.47 inches tall (204.4 cm), the AR7005 spans the full height of a 45U rack frame. The perforated curved design is not decorative — perforation supports front-to-back airflow through the door panel, which matters when you are running high-density switching, patch, or compute equipment that generates significant heat. A solid door on a hot rack is a thermal problem waiting to happen; this door avoids that.

Key Features

• Full 45U Height Coverage (80.47 in / 204.4 cm): Spans the complete frame of a NetShelter SX 45U enclosure — no gaps at top or bottom that would disrupt containment airflow or leave equipment exposed.
• Perforated Panel Airflow: The curved perforated face allows ambient air to enter the front of the enclosure rather than blocking it. In any rack running more than a few 1U switches or servers, front-door airflow is a direct factor in equipment operating temperature and longevity.
• 24.93 lb (11.31 kg) Constructed Weight: Substantial enough to indicate full-steel construction consistent with NetShelter SX standards — not a lightweight aftermarket substitute. Plan accordingly for single-person installs; the door is manageable but awkward at this size.
• Direct Chassis Fit for NetShelter SX 600mm Wide Frames: Engineered to mount on the 600mm-wide NetShelter SX enclosure family without drilling, adapter plates, or shimming. Replacement is a hinge-pin and latch swap, not a fabrication project.
• Black Finish: Matches standard NetShelter SX aesthetic — relevant if the rack is in a customer-facing data room, NOC, or security operations center where visual uniformity matters.

Compatibility

The AR7005 is designed for APC NetShelter SX enclosures that are 45U in height and 600mm in width. Verify your existing enclosure model number before ordering — NetShelter SX racks are available in multiple widths (600mm and 750mm) and depths; the 750mm-wide variants use a different door. If your enclosure is a NetShelter VX, VS, or a non-APC brand, this door will not fit without modification. Check the enclosure's model label on the frame rail before purchasing.

Frequently Asked Questions

Q: What rack enclosure models is the AR7005 compatible with?

A: The AR7005 is designed for APC NetShelter SX 45U enclosures with a 600mm wide frame. Confirm your enclosure is a 600mm-wide NetShelter SX 45U variant before ordering — the 750mm-wide NetShelter SX uses a different door.

Q: Does the AR7005 affect airflow through the rack?

A: The perforated curved design allows front-to-back airflow through the door panel, supporting proper thermal management for active equipment. It does not restrict intake air the way a solid door would.

Q: How heavy is the AR7005 and do I need two people to install it?

A: The door weighs 24.93 lb (11.31 kg). At 80.47 inches tall, a second person makes installation significantly easier and reduces the risk of damaging the hinge pins or frame during fitting.

Q: Is the AR7005 a rack-mountable component?

A: No. The AR7005 mounts as the front door of a NetShelter SX 45U enclosure — it is not rack-mountable in the traditional 1U/2U sense. It replaces or adds a front door to the enclosure chassis.

Jerry Tildsen

The AR7005 is one of those parts that only matters when you need it — and when you do, getting the right fit the first time is everything. At 80.47 inches and 24.93 lb, this is a full-height front door for the NetShelter SX 45U 600mm enclosure, not a generic rack accessory. I have seen integrators order the 750mm variant by mistake; double-check your enclosure width label before the order ships.

Technical Highlights:

• 80.47 in Full-Height Coverage: Sized precisely for the 45U NetShelter SX frame — no gap at top or bottom that could compromise hot/cold aisle containment or leave a cable entry point exposed.
• Perforated Curved Face: Airflow through the door is not incidental — it is the design intent. In a loaded rack running switches, patch panels, and active compute, a solid replacement door here would be a thermal liability.
• 24.93 lb Steel Construction: Matches the OEM weight profile of the NetShelter SX door family, which tells you this is full-gauge steel — not a lightweight aftermarket substitute that flexes on the hinge pins over time.

Deployment Considerations:

• Verify your NetShelter SX enclosure is 600mm wide before ordering — this door does not fit the 750mm-wide NetShelter SX variants, and the two widths look similar on the floor.
• At just over 80 inches tall and nearly 25 lb, a solo install is physically awkward. Budget two people for the hinge-pin alignment step to avoid bending the frame or stripping the hinge hardware.

The AR7005 fits cleanly in any NOC, security operations center, or data room retrofit where you need to restore an enclosure door to OEM spec without sourcing a full replacement rack — straightforward swap for facilities teams maintaining an existing NetShelter SX 45U 600mm install.
