Panduit NK6X88MWH-Q NETKEY CAT6A PUNCHDOWN JACK MOD

Overview

The Panduit NK6X88MWH-Q is a Category 6A punchdown jack module designed for high-performance structured cabling systems. It terminates 23-26 AWG solid or stranded conductors, providing a reliable connection point for 10 Gigabit Ethernet networks. This module is essential for building robust data infrastructure in enterprise, data center, and industrial environments where network speed and integrity are critical. Its white color aids in visual organization within patch panels and wall plates.

Compatibility

This jack module is designed for use with Panduit NETKEY modular patch panels, faceplates, and surface mount boxes. It supports termination of standard Category 6A cabling infrastructure, ensuring backward compatibility with Category 6 and Category 5e systems when used within a complete Category 6A channel.

Installation Notes

Termination requires a standard 110 punchdown tool. Ensure conductors are punched down fully to seat them correctly in the IDC contacts. Follow TIA-568-C.2 standards for proper cable management and termination to achieve optimal performance and meet certification requirements. Maintain proper bend radius for the cable pairs to avoid signal degradation.
