Pelco IMF-PM Pendant Mount Adapter

Overview

The Pelco IMF-PM is a pendant mount adapter designed to suspend Pelco fisheye cameras from overhead structures — ceilings, beams, or canopies — for 360-degree panoramic coverage without blind spots. This NDAA-compliant accessory solves the installation constraint when you need a camera centered in a large open area (retail floors, atriums, airports, warehouses) and wall or corner mounting won't work. The adapter enables secure pendant-style deployment while maintaining the fisheye's panoramic field of view from a single vantage point, reducing overall deployment costs compared to multi-camera linear coverage.

Compatibility

The IMF-PM is engineered for the Pelco IMF fisheye camera family, including the 8 MP and 12 MP panoramic models. It supports surface-mount, in-ceiling, and pendant mounting configurations. Confirm exact compatibility with your specific IMF model and mounting enclosure before ordering; the adapter is designed as an accessory within the Pelco fisheye ecosystem.

Installation Notes

Pendant mounting requires structural overhead support rated to handle the camera's weight plus adapter mass. The IMF-PM maintains the camera's IP66/IP67 environmental rating when properly sealed, making it safe for both indoor and outdoor deployments (rated IK10 for vandal resistance). Wiring passes through the pendant support; ensure PoE+ (802.3at) power is available at the run point — the camera draws up to its rated wattage from standard PoE+ sourcing. Operating temperature range is −10°C to +70°C; verify your climate zone falls within this window, particularly for outdoor installations in extreme cold or heat.
