Vertiv I10001 Vertical Rack PDU — 24-Outlet 20A Upgradeable Power Distribution

Overview

The Vertiv I10001 (model MN01X4B0-24D203-2ST5A0A10-S) is a 66-inch vertical rack power distribution unit built for data centers and equipment-dense rack deployments where you need reliable power distribution today and want the option to add monitoring without pulling the unit. Rated at 20A/120V with a 1.9kW load capacity, it ships as a basic unit with no monitoring overhead — but unlike fixed-basic PDUs, it accepts Vertiv's Interchangeable Monitoring Device (IMD) hot-swap module, letting you upgrade to metered or monitored operation in the field without replacing the PDU itself.

Every I10001 is 100% factory-tested before shipment. It ships with a 10-foot power cord and NEMA 5-20P plug, ready to connect to a standard 20A branch circuit. TAA-compliant and Buy American Act COTS-compliant, it fits procurement programs that require domestic manufacturing accountability. Explore the full Vertiv power infrastructure lineup for complementary products across the rack PDU, UPS, and thermal management categories.

Key Features

• 24x NEMA 5-20R Receptacles in Duplex Configuration: Twenty-four outlets in a 66-inch vertical form factor gives you high outlet density without sacrificing access — duplex spacing means you can plug in standard IEC or NEMA power cords without fighting for clearance. For a fully populated 42U rack, that's enough outlets to power every 1U device without daisy-chaining power strips.
• Geist IMD Hot-Swap Upgradeable Architecture: The core value proposition of this unit is field upgradeability. Rather than purchasing a monitored PDU from day one, you can deploy the I10001 as a basic unit and add the appropriate IMD module later — without taking the rack offline. This defers the monitoring cost until you actually need it, which matters when deploying across dozens of racks on a budget.
• 20A / 120V / 1.9kW Load Capacity: Sized for a standard 20A branch circuit (NEMA 5-20P plug). At 1.9kW continuous, this unit comfortably handles a mixed rack of 1U servers, network switches, and storage — but if your rack draw approaches or exceeds that figure, calculate per-outlet loads before deployment. No over-current protection is built in, so the upstream breaker is your protection.
• 66-Inch Vertical Rackmount, Toolless Mounting: Mounts vertically in a standard cabinet with center-to-center spacing options at 61.25 inches and 64.75 inches — compatible with most common rack rail configurations. The toolless mounting hardware means installation doesn't require running down a screwdriver during a high-pressure rack build. Power entry is at the bottom front, which keeps cable runs clean in most vertical-PDU deployments.
• 12/3 AWG Power Cable, 10ft / 3m Cord: The 12-gauge wiring is correctly matched to the 20A rating — you won't get voltage drop or heat buildup at load that you'd see with an undersized cable. The 10-foot cord gives you enough reach to connect to a floor-mounted PDU panel or overhead whip without an extension.
• 60°C / 140°F Maximum Operating Temperature: This rating accommodates hot-aisle/cold-aisle configurations where ambient temperatures at the rear of the rack can spike. Data center environments running above 45°C ambient should still verify rack-level thermal management, but this rating provides meaningful headroom for high-density deployments.
• UL & c-UL Listed (62368-1), RoHS, FCC Part 15 Class A: UL 62368-1 is the current audio/video, IT, and communications equipment safety standard — the relevant listing for rack PDUs. FCC Part 15 Class A is the commercial emissions conformance (not for residential use). RoHS compliance matters for facilities with environmental procurement requirements. These certifications are all SKU-verified for the I10001.
• TAA-Compliant, Buy American Act COTS Compliant, Made in USA: For federal, DoD, or GSA-schedule procurement, TAA compliance is often a hard gate. This unit clears that requirement. If your project is a government data center buildout, this matters at the contract level — not just as a nice-to-have.
• 5-Year Limited Warranty: Vertiv's five-year limited warranty on the I10001 is longer than the typical three-year window on commodity PDUs — relevant when deploying in a rack that you expect to keep in service for a full refresh cycle.
• Heavy Steel Powder Coat Finish, 15 lbs Shipped Weight: The steel chassis is rigid enough to handle a full cable bundle without flex. At 15 lbs shipped, it's manageable for a two-person rack installation. The black powder coat finish is standard for dark-interior cabinet deployments.

Integration & Compatibility

The I10001 connects to any 20A NEMA 5-20 branch circuit — standard in North American data centers and server rooms. All 24 outlets are NEMA 5-20R, compatible with the vast majority of rack-mount equipment power cords. For environments running IEC C13/C14 or C19/C20 devices, verify cord compatibility or use appropriate adapters before deployment.

The IMD upgrade path is specific to Vertiv's Geist IMD ecosystem — the monitoring module must be a Vertiv-compatible IMD unit. Before planning a monitoring upgrade, confirm IMD model compatibility with the I10001 form factor through Vertiv's product documentation. This is not a universal monitoring upgrade path; it works within the Vertiv Geist PDU family. For a broader look at rack power distribution units across multiple configurations, including pre-monitored options, that category page covers alternatives if your monitoring requirements are immediate rather than future-state. If you're planning a larger rack deployment, pairing with an uninterruptible power supply upstream is standard practice for any environment requiring runtime during utility outages. For rack infrastructure planning guidance, consult a rack management resource to match PDU outlet density with your actual load profile before committing to a configuration.

Frequently Asked Questions

Q: Can the I10001 be upgraded to a monitored PDU without replacing the unit?

A: Yes. The I10001 uses Vertiv's Geist hot-swap IMD (Interchangeable Monitoring Device) architecture. You can add the appropriate IMD module in the field to upgrade from basic to metered or monitored operation without removing the PDU from the rack. The specific IMD model must be compatible with this unit — verify with Vertiv's PDU accessory documentation before purchasing.

Q: What is the maximum load capacity of the I10001?

A: The I10001 is rated at 20A input current at 100–120V, with a 1.9kW load capacity. It connects via a NEMA 5-20P plug to a dedicated 20A branch circuit. There is no built-in over-current protection — the upstream breaker provides circuit protection.

Q: Is the I10001 TAA-compliant for government procurement?

A: Yes. The I10001 is TAA-compliant and Buy American Act COTS-compliant, manufactured in the USA. It is suitable for federal, DoD, and GSA-schedule procurement programs that require domestic manufacturing compliance.

Q: What certifications does the I10001 carry?

A: The I10001 is UL & c-UL Listed to the 62368-1 safety standard, RoHS compliant, and FCC Part 15 Class A conformant. These certifications are verified for this SKU.

Q: What is the warranty on the I10001?

A: Vertiv provides a 5-year limited warranty on the I10001, as documented on the Vertiv product specification sheet for this part number.

Q: How many outlets does the I10001 have, and what outlet type?

A: The I10001 has 24 NEMA 5-20R receptacles in duplex configuration, all rated at 120V. This makes it compatible with standard North American rack equipment using NEMA 5-20P or 5-15P plugs (with appropriate cords).

Ted Perry

The I10001 is the unit I'd recommend when a customer knows they want monitoring visibility eventually but can't justify the cost across 40 racks on day one. That Geist IMD hot-swap slot is the deciding spec — it means you're not locked into a basic PDU forever, and you're not paying the monitored premium on every cabinet from the start. At 20A/1.9kW with 24 NEMA 5-20R outlets in a 66-inch vertical format, this unit is correctly sized for a standard North American mixed-load rack running servers, switches, and storage at realistic utilization.

Technical Highlights:

• IMD Upgrade Path: The hot-swap Interchangeable Monitoring Device slot lets you add metered or monitored capability without taking the rack offline — critical in live environments where you can't schedule downtime for a PDU swap.
• 12/3 AWG Wiring at 20A: 12-gauge conductors properly matched to the 20A rating mean no derating concerns at sustained load. This is not always a given on commodity PDUs where wire gauge is left ambiguous in the datasheet.
• 60°C Operating Ceiling: Hot-aisle temperatures in high-density cabinets can easily exceed 45°C ambient behind the rack. The 60°C maximum operating temperature rating gives you real headroom, not just a spec-sheet checkbox.

Deployment Considerations:

• The 10-foot NEMA 5-20P cord covers most floor-to-cabinet or overhead whip installations, but measure your branch circuit distance before assuming — in deep or offset rack rows, 10 feet can come up short without a cord extension plan.
• There is no built-in over-current protection on the I10001. Your upstream 20A breaker is the only protection in the circuit. If a load event trips the breaker, you're taking down all 24 outlets simultaneously — factor this into your availability design for any single-corded equipment in the rack.

This unit is the right fit for a phased federal data center buildout or enterprise colocation deployment where procurement requires TAA compliance today and monitoring requirements will be defined after initial rack commissioning — the IMD upgrade path keeps both options open without a forklift replacement.
