Hanwha WRT-P-3104W Mini-tower WAVE Recording Server

Hanwha WRT-P-3104W Mini-tower WAVE Recording Server

The Hanwha WRT-P-3104W is a compact, purpose-built Network Video Recorder designed for single-site deployments and multi-site expansions within Wisenet WAVE environments. This mini-tower server combines integrated hardware and pre-installed Wisenet WAVE VMS software into one ready-to-deploy unit, eliminating complex setup workflows for security integrators and IT managers. With 170 Mbps recording throughput, support for up to 64 IP camera channels, and flexible storage expansion up to 16TB raw capacity, the WRT-P-3104W delivers scalable surveillance infrastructure for small to mid-market enterprise networks.

Key Features

• 170 Mbps simultaneous recording throughput for multi-camera deployments without server bottlenecking
• Wisenet WAVE VMS pre-installed with up to 64 IP camera channel support
• 4 Professional VMS licenses included for immediate multi-user operation
• 14th Generation Intel Core i3 processor for responsive VMS performance and smooth playback
• 16GB DDR4 memory for stable operation under sustained multi-stream recording and client access
• 1x 256GB M.2 SSD for operating system and application layer
• 3x 3.5" SATA HDD bays with 4TB raw capacity (expandable to 16TB raw)
• 3.5mm audio input (front) and output (rear) for integrated audio monitoring
• MicroSD card slot for flexible configuration backup and expansion
• 80 Plus Gold power efficiency certification
• UL, cUL, CB, and FCC certifications for regulatory compliance
• Operating temperature range: 50°F to 95°F (10°C to 35°C)

Technical Highlights

The WRT-P-3104W leverages 14th generation Intel processing to deliver responsive VMS operation without compromise. The hybrid storage architecture—combining a dedicated 256GB M.2 SSD for the OS with three SATA HDD bays—ensures fast system responsiveness while providing substantial capacity for extended video retention. With 16GB of DDR4 memory, the server handles concurrent recording streams, live client viewing, and playback operations without degradation. The 170 Mbps recording bandwidth accommodates high-resolution IP cameras across all 64 supported channels, critical for modern surveillance deployments requiring 4MP, 5MP, and higher resolution feeds.

Applications

Ideal for retail chains, office complexes, educational institutions, healthcare facilities, and hospitality operations requiring centralized IP video management. The WRT-P-3104W serves as both a primary recording solution for single-site installations and as an expansion node for organizations scaling existing Wisenet WAVE systems across multiple locations.

Jerry Tildsen

The WRT-P-3104W represents a mature, production-hardened appliance for mid-market surveillance deployments. The inclusion of pre-installed Wisenet WAVE VMS with 4 Professional licenses eliminates licensing friction and accelerates time-to-deployment—a significant advantage for integration partners managing multiple installations. The 170 Mbps throughput paired with 64-channel capacity positions this unit well for organizations seeking to consolidate recording infrastructure without overprovisioning.

Storage expandability to 16TB raw supports extended retention strategies, particularly valuable in regulated industries. 80 Plus Gold efficiency and thermal design specifications indicate mature engineering, while multi-certification (UL, cUL, CB, FCC) underscores suitability for varied deployment environments. For teams already invested in Wisenet ecosystems, this appliance delivers predictable performance and straightforward scalability.
