Panduit CJ688TPRD Concise Descriptor

Overview

The Panduit CJ688TPRD is a Category 6 UTP (Unshielded Twisted Pair) keystone jack designed for high-performance network installations. It provides a robust termination point for network cabling, ensuring reliable data transmission for applications requiring stable connectivity, such as IP surveillance systems or enterprise data networks. This jack is engineered for quick termination using standard punch-down tools, simplifying the installation process in structured cabling deployments.

Compatibility

This keystone jack is compatible with standard UTP Category 6 network cables. It is designed to fit into standard keystone patch panels, wall plates, and surface mount boxes that accept 110-style punch-down connectors. It is suitable for use with various network infrastructure components that adhere to TIA/EIA-568-C.2 standards for Category 6 cabling.

Installation Notes

Utilizes a 110-style punch-down termination. Ensure proper conductor seating with a TIA-compliant punch-down tool to achieve optimal performance and reliability. Terminate wires according to the color-coded wiring diagram provided on the jack to maintain pair untwist and meet Category 6 specifications. Recommended for use with Panduit's comprehensive line of network infrastructure products for guaranteed system performance.
