Lifesafety Power FPO150-F8PE1 150W Supervised Power Supply
Overview
The FPO150-F8PE1 is a Class 2 power-limited supply designed for security installations requiring multiple supervised output circuits. The unit delivers 150W across selectable 12V or 24V rails, with eight isolated FAI (Failsafe Alarm Interface) control outputs rated at 2.5A per output. This architecture allows you to power and supervise up to eight separate sensor or device branches independently—critical in access control, fire alarm integration, and multi-zone security deployments where fault isolation and branch supervision are required by code or system architecture.
Electrical Specifications
The FPO150-F8PE1 provides either 12A at 12VDC or 6A at 24VDC, giving you flexibility in system voltage selection based on device requirements and wire run distances. Each of the eight control outputs is independently supervised and current-limited to 2.5A, preventing cascading failures if a downstream device shorts or draws excess current. Class 2 power-limited operation means the supply meets UL/NEC safety requirements for low-voltage control circuits, eliminating the need for heavy-gauge wiring and conduit in many jurisdictions. If your installation requires supervised power distribution with redundancy or battery backup, verify battery expansion module compatibility with the FPO150-F8PE1 before specifying.
Installation Context
Mount the unit in a secure equipment enclosure or cabinet. The E1 designation indicates a standard metal housing suitable for wall or rack installation in indoor, climate-controlled environments. Ensure adequate ventilation around the unit and confirm that branch loads do not exceed 2.5A per FAI output. Coordinate with your system integrator or access control power planning guide to verify total load distribution and any required backup battery capacity.
