Middle Atlantic LH Cnsl Xtype MED S - LH-XTCMS

Middle Atlantic LH-XTCMS Lund/Halsey X-Type Medium Broadcast Console

The Middle Atlantic LH-XTCMS is a 63-inch-wide, 6RU X-type operator console built for command-and-control environments where two monitors, rack-mounted gear, and a clean worksurface need to coexist at shift scale. This is the medium-depth variant in the Lund/Halsey X-type broadcast console line — 39.4 inches deep and 29 inches tall — sized for master control rooms, security operations centers, and broadcast production desks where the operator works at the station for hours at a time. At 504 lbs, the LH-XTCMS ships flat and installs in place, so plan your access path before delivery.

Overview

The Lund/Halsey X-type console family is Middle Atlantic's broadcast-heritage workstation platform, engineered around integrated rack capacity and structured monitor positioning rather than afterthought accessory mounts. The LH-XTCMS hits the mid-size slot in that family: wide enough for a two-operator or single-operator-with-spread layout, deep enough for a full equipment complement, and finished in a Black/Silver/Gray frame with White worksurface — a combination that reads cleanly under studio and operations-center lighting without washing out on camera. The console is TAA compliant and sourced from the United Kingdom, making it eligible for federal and government procurement programs that require TAA-origin hardware.

Key Features

• 63-inch working width: At 160 cm wide, the LH-XTCMS gives a two-person crew shoulder room or lets a single operator spread monitors, a control surface, and peripherals without stacking. For security operations consoles where crowding causes errors, width is a safety spec, not an aesthetic one.
• Dual monitor mounting (2 displays): Integrated two-display mounting means monitors are positioned relative to the console's geometry — correct sight lines, correct ergonomic angle — not shimmed up on ad-hoc risers. If your workflow requires two independent feeds or a primary-plus-secondary layout, this is built in, not bolted on.
• 6 RU of integrated rack capacity, cage nut rail type: Six rack units with cage nut rails means you can drop in a standard 1RU or 2RU device without adapters. Cage nut systems are the correct choice for mixed-vendor equipment rooms where rail compatibility is never guaranteed — every standard rack device fits. Pair this with a rack management accessory if you need blanking panels or cable guides in unused RU slots.
• 39.4-inch depth: The 100.1 cm depth accommodates full-depth rack equipment (servers, matrix switchers, large NVR chassis) without the equipment protruding behind the console frame. Shallower consoles force you to leave deep gear out of the rack bay or leave the rear panel exposed — this depth avoids that tradeoff.
• 29-inch fixed working height: No electric lift on this model — height is fixed at 29 inches (73.7 cm). That's a standard desk-height dimension suited to seated operation. If standing-desk or height-adjustable operation is a requirement, that spec eliminates this SKU; verify before quoting.
• 504 lb assembled weight, ships flat: The flat-ship format means the LH-XTCMS moves through standard freight without requiring a pre-assembled footprint — valuable for facilities with narrow corridors or elevator size constraints. The 504 lb installed weight means the floor loading calculation matters; confirm your floor's capacity, especially in upper-story control rooms.
• TAA compliant, UK origin: Federal Ops Country of Origin is United Kingdom. TAA compliance means this unit satisfies Trade Agreements Act requirements for U.S. government procurement. If your project has a Buy American or TAA clause, this console qualifies. Verify the project's specific clause language — TAA and BAA are distinct requirements.
• Black/Silver/Gray frame, White worksurface: The two-tone finish is a deliberate design choice for broadcast and operations environments: the dark frame reduces reflections in low-light rooms while the white worksurface improves document and keyboard visibility under task lighting. For camera-facing installations (broadcast control), this reads well without creating hotspots.
• Available internationally: The LH-XTCMS ships to international destinations, relevant for global broadcast infrastructure projects or multinational enterprise security deployments. Verify local freight and installation requirements for non-US destinations.

Integration and Compatibility

The LH-XTCMS integrates into any command and control furniture environment that requires structured rack capacity at the operator position. The 6 RU cage nut rack bay is compatible with standard 19-inch rack equipment — video matrix switchers, KVM units, intercom frames, NVR appliances, and audio routers all mount without modification. The dual monitor mount positions support industry-standard VESA-compatible displays; verify monitor arm VESA pattern against your chosen display before finalizing. The fixed-height worksurface integrates with adjacent console sections in multi-bay layouts; the X-type form factor is designed to pair with matching Middle Atlantic console sections for expanded operator positions. For broader Middle Atlantic technical furniture options including add-on side tables, monitor risers, and cable management panels, review the full console accessory line to complete the installation.

Frequently Asked Questions

Q: Is the LH-XTCMS TAA compliant for federal government procurement?

A: Yes. The LH-XTCMS is TAA compliant, with a Federal Ops Country of Origin of United Kingdom — a TAA-designated country. It is eligible for U.S. federal procurement programs subject to TAA requirements. Always verify the specific clause in your project contract, as TAA and Buy American Act requirements differ.

Q: What rack rail type does the LH-XTCMS use, and what equipment will fit?

A: The LH-XTCMS uses cage nut rails — the standard 19-inch rack format. Any standard 1RU, 2RU, or multi-RU device designed for a cage nut rack will install without adapters. The console provides 6 RU of capacity total.

Q: Is the LH-XTCMS height adjustable or available with an electric lift?

A: No. The LH-XTCMS has a fixed working height of 29 inches (73.7 cm) and does not include an electric lift or height adjustment mechanism. If sit-stand or height-adjustable operation is required, this model does not support it — evaluate other configurations in the Lund/Halsey line.

Q: How many monitors does the LH-XTCMS support?

A: The LH-XTCMS is configured for 2 displays. The monitor mounting is integrated into the console's design, not an add-on accessory.

Q: What are the shipping and installation logistics for the LH-XTCMS?

A: The LH-XTCMS ships flat (Ships Flat: Yes), which makes freight through standard doorways and elevators feasible. However, the assembled weight is 504 lbs (228.6 kg) — floor loading and lift equipment at the installation site must be confirmed before delivery. Plan the access route from loading dock to final position before scheduling delivery.

Q: Is the LH-XTCMS available for international shipment?

A: Yes, the LH-XTCMS is listed as available internationally. Contact your freight coordinator for country-specific import and logistics requirements.

Marty Allison

I specify the LH-XTCMS for master control room builds and security operations centers where the operator position needs to carry real rack equipment — not just a keyboard tray and a couple of monitors. The 6 RU cage nut bay inside a 63-inch-wide frame is the spec that matters here: you get a video matrix, a KVM switch, or an intercom frame mounted at arm's reach without running a separate equipment rack behind the operator. That's the console doing actual work, not just holding monitors.

Technical Highlights:

• 63-inch width (160 cm): Wide enough for a two-person shift or a single operator with a full peripheral spread — control surfaces, intercom panels, and two independent monitor feeds fit without the clutter that causes operational errors during high-stress events.
• 504 lb assembled weight, flat-ship: Ships flat for freight logistics, but at 504 lbs the installed unit is permanent. Once it's down and loaded with equipment it's not moving — factor that into your room layout and floor loading review before the truck arrives.
• TAA compliant, UK origin: For government integrators, TAA compliance on the LH-XTCMS clears the primary procurement hurdle on federal and state projects with trade agreement clauses. The UK is a TAA-designated country — document it in your submittal package and move on.

Deployment Considerations:

• The fixed 29-inch working height is correct for seated single-shift operation but eliminates this model from any project spec that requires sit-stand or height-adjustable positions — verify the ergonomic requirements with the end user before quoting, not after.
• The integrated 6 RU is cage nut only — if your equipment mix includes toolless or snap-in rail devices, those will require cage nut adapters. Confirm with your AV or IT equipment vendor before finalizing the rack complement.

The LH-XTCMS is the right call for broadcast master control rooms and 24/7 security operations centers that need a production-grade operator station with onboard rack capacity — specifically where TAA compliance is a contract requirement and two-display layout is the standard operating configuration.
