Lenovo 7XH7A02684 Thinksystem SR630 X16ML2/X8 PCIE Lp+lp Riser 1 KIT

Lenovo 7XH7A02684 ThinSystem SR630 X16ML2/X8 PCIe LP+LP Riser 1 Kit

Overview

The Lenovo 7XH7A02684 is a PCIe riser kit designed to provide additional expansion slots for compatible Lenovo ThinkSystem servers. This specific kit, model number 7XH7A02684, facilitates the installation of low-profile (LP) PCIe cards, enabling enhanced functionality and connectivity within the server chassis. It is engineered for seamless integration into the ThinkSystem SR630 platform, ensuring proper fit and electrical connection for PCIe x16 and x8 devices.

Compatibility

This riser kit is specifically designed for the Lenovo ThinkSystem SR630 server. It supports the installation of low-profile PCIe cards into the designated slots on the server motherboard. Ensure your server model is the ThinkSystem SR630 before ordering, as compatibility is strictly limited to this chassis.

Installation Notes

The Lenovo 7XH7A02684 kit includes mounting hardware and is designed for a direct installation into the ThinkSystem SR630. Proper seating of the riser card into the motherboard slot and secure mounting of the PCIe cards are critical for reliable operation. The dimensions are 11.50 x 10.00 x 2.00 inches (L x W x H), which must fit within the server's internal clearance. The interface type is PCIe.
